main product photo

DANFOSS / EATON-XLH Series, Spool Valve

Ask A Question

Description & Features

Designed for low-speed, high-torque hydraulic applications, the Danfoss / Eaton XLH Series Spool Valve delivers a torque rating of 104 Nm with a maximum flow rate of 45 litres per minute. Built around a Gerotor/Geroler motor design, it is well-suited to demanding mobile and industrial hydraulic circuits where reliable low-speed performance is a priority.

Sold under the Char-Lynn brand, this Xcel Series unit incorporates an efficient disc valve mechanism that maintains consistent output speed, alongside a spool valve configuration that supports precise directional control. The advanced design balances performance capability with cost-effective construction, making it a practical choice for a range of medium-duty hydraulic drive applications.

SKU: 016-0298-002

Supplier Part Number (MPN): 016-0298-002

Specifications

Brand
Danfoss
Bearing Type
Hydrodynamic Journal
Check Valve Function
Without Check Valve Function
Color
Black
Design Code
B
Dimensions
5.67 in L x 5.12 in W x 3.7 in H
Frame Size
65
Housing Material
Iron
Mounting Type
2-Bolt Flanged
Orbital Gearwheel Set
Standard
Orbital Gearwheel Set Type
Gerotor
Painted
With Painted
Port Location
Side, Staggered
Port Type
UNF-2B, SAE O-ring
Seal Material
NBR
Series
XLH Series
Shaft Size
1 in Dia
Shaft Type
Straight Square Keyed
Valve Type
Spool

Product Questions & Answers (1)

Question by: Floyd M on Apr 11, 2025, 6:40 PM
reckon this'd be alright runnin' steady on a hydraulic splitter?
Answer by: Customer Support on Apr 13, 2025, 6:16 AM
This Danfoss/Eaton XLH series spool valve is well-suited for demanding industrial hydraulic circuits where reliable low-speed performance is a priority, so it should handle the steady use on a hydraulic splitter just fine.
