main product photo

DANFOSS / EATON-XLH Series, Spool Valve

Ask A Question

Description & Features

Designed for applications in aerial work platforms and food processing, the DANFOSS / EATON-XLH Series Spool Valve offers exceptional performance in low-speed use. This robust valve is constructed from durable cast iron and features an advanced design that delivers higher torque at low speeds, with a torque rating of 318 newton metres. The efficient "same speed" disc valve enhances its operational efficiency, supporting a flow rate of 57 litres per minute. The Char-Lynn brand ensures reliability and longevity, making it an excellent choice for demanding industrial environments where precision and durability are paramount.

SKU: 016-0303-002

Supplier Part Number (MPN): 016-0303-002

Specifications

Brand
Danfoss
Bearing Type
Hydrodynamic Journal
Check Valve Function
Without Check Valve Function
Color
Black
Design Code
B
Dimensions
7.575 in L x 5.12 in W x 3.7 in H
Frame Size
240
Housing Material
Iron
Mounting Type
2-Bolt Flanged
Orbital Gearwheel Set
Standard
Orbital Gearwheel Set Type
Gerotor
Painted
With Painted
Port Location
Side, Staggered
Port Type
UNF-2B, SAE O-ring
Seal Material
NBR
Series
XLH Series
Shaft Size
1 in Dia
Shaft Type
Straight Square Keyed
Valve Type
Spool

Product Questions & Answers (2)

Question by: Earl G on Aug 29, 2025, 8:15 AM
got a slow moving setup on an aerial lift, is this valve actually meant for low-speed work
Answer by: Customer Support on Aug 31, 2025, 6:44 AM
Built around a low-speed gerotor style, it is aimed at applications where you need solid torque without having to run the system fast. The XLH series is called out for aerial work platforms and is rated for higher torque at low speeds, with a 318 newton metre torque rating.
Question by: Ralph K on Oct 17, 2025, 6:37 PM
torque on this thing rated at 318 newton metres -- is that enough grunt for aerial lift platforms running slow cycles all day?
Answer by: Customer Support on Oct 19, 2025, 5:41 PM
For low-speed aerial work platform use, 318 newton metres of torque is right in the wheelhouse for this motor. The XLH series is built around exactly that kind of application, so the torque rating lines up with the demands of slow, controlled lifts rather than high-speed rotation. The gerotor design specifically pulls more torque out at low speeds, which is where aerial platforms spend most of their working time anyway.
