VICKERS DG18V 3 2B T 60

Description & Features

Designed for three- or four-way directional control in demanding industrial hydraulic circuits, the Vickers DG18V 3 2B T 60 is a single-stage directional control valve rated for flow up to 75 litres per minute. Buna-N seals provide reliable fluid compatibility across a wide range of standard hydraulic media.

The valve mounts on industry-standard surfaces, supporting straightforward integration into existing machine configurations. Its application range spans die casting and foundry equipment, machine tools, marine and offshore systems, presses, primary metal processing, paper machinery, test and simulation equipment, and turbine control systems, making it a versatile choice across multiple industrial sectors.

SKU: 02-134327

Supplier Part Number (MPN): 02-134327

Specifications

Actuator Type Air, Solenoid	Design 60 Series	Dimensions 5.77 in L x 1.81 in W x 1.96 in H	Domestic/Import Domestic	Indicator Light Without Indicator Light	Language English	Manual Override Operator End	Media Petroleum Oil	Number of Stages 1	Performance Standard-Performance	Pilot Source Thread 1/8 in BSP	Seal Material FKM	Series DG18V-3 60 Series	Spool Position Monitor Without Spool Position Monitor	Spool Type Spool 2	Spring Arrangement Spring Centered A Removed	Surge Suppressor Damper Without Surge Suppressor Damper	Valve Mount Type Subplate/Manifold

Product Questions & Answers (2)

Question by: Travis A on Oct 30, 2025, 12:39 PM

Flow rate on this one says 75 litres per minute, that enough for a press circuit running a decent-sized cylinder, or is this more of a mid-range valve?

Answer by: Customer Support on Nov 1, 2025, 7:35 AM

For most press applications, 75 litres per minute gives you solid capability without being overkill. This valve sits comfortably in the mid-to-upper range for single-stage directional control, and press equipment is explicitly listed as one of its intended uses. Whether it fits your specific cylinder sizing depends on your flow demand calculations, but the rating is genuine working capacity, not a peak-only figure.

Question by: Scott P on Sep 13, 2025, 4:23 PM

So, this thing controls direction, but what kind of machines is it good for?

Answer by: Customer Support on Sep 15, 2025, 6:27 AM

This Vickers directional control valve is a good fit for die casting, foundry equipment, machine tools, marine and offshore systems, presses, primary metal processing, paper machinery, test and simulation equipment, and turbine control systems. It's a pretty versatile piece of equipment.
