Vickers CG5 060A F M U B6

Description & Features

Designed for hydraulic circuits requiring precise pressure management, the Vickers CG5 060A F M U B6 is an adjustable pressure control valve suited to applications where limiting circuit pressure to a defined maximum is essential. It functions as both a pressure relief and regulating valve, making it a practical choice across a range of industrial hydraulic systems.

Rated for flow up to 227 litres per minute, this CG5-06 series valve features a plug-and-play design that simplifies installation and replacement. Buna-N seals provide reliable fluid compatibility in standard hydraulic media, while moisture-resistant construction supports durability in demanding environments. The valve carries the Vickers brand under the Danfoss/Eaton portfolio.

SKU: 02-140840

Supplier Part Number (MPN): 02-140840

Specifications

Actuator Type Pilot Operated, Solenoid	Adjustment Type Screw with Locknut	Body Material Iron	Design 110 Series	Dimensions 5.75 in L x 2.81 in W x 9.65 in H	Domestic/Import Domestic	Hi-Vent Spring Without Hi-Vent Spring	Indicator Light Without Indicator Light	Manual Override Plain	Media Petroleum Oil	Nominal Size #06	Number of Stages 2	Performance Standard	Seal Material Buna-N	Series CG5-06 Series	Spring Arrangement Spring Offset	Valve Mount Type Subplate/Manifold	Voltage Rating 110 VAC at 50 Hz, 120 VAC at 60 Hz

Product Questions & Answers (1)

Question by: Roger S on Apr 23, 2025, 11:38 AM

flow rate on this thing is listed at 227 litres per minute -- that enough for most standard industrial hydraulic setups or is it pushing the upper end?

Answer by: Customer Support on Apr 24, 2025, 6:20 PM

For the majority of industrial hydraulic circuits, 227 litres per minute puts this valve well within a comfortable working range. It's not a limiting factor in most shop floor or mobile equipment applications. Where you'd want to pay closer attention is if your system runs sustained peak demands close to or above that number, since the valve is rated to that ceiling, not beyond it.
