VICKERS RV1 10 K 6T 9/

Ask A Question

Description & Features

Designed for mobile and industrial hydraulic circuits, this poppet-style pressure control valve handles flow rates up to 30 litres per minute through a 3/8" port. The RV1-10 Series is rated for pressures up to 350 bar (5,000 psi) with a maximum system flow capacity of 300 L/min (80 USgpm), making it well suited to demanding applications including harvesters and refuse haulers.

The Vickers RV1 10 K 6T 9/ combines a compact form factor with reliable pressure regulation, offering installation flexibility where space is limited. Its poppet construction provides consistent seating and repeatable performance across a range of industrial and mobile duty cycles.

SKU: 02-164567

Supplier Part Number (MPN): 02-164567

Specifications

Actuator Type
Direct Acting
Adjustment Type
Knob
Body Material
Steel
Cavity
C-10-2
Connection Type
SAE
Dimensions
2.5 in L x 2 in W x 5.8 in H
Domestic/Import
Import
End Type
SAE
Housing
With Housing
Installation Type
Screw-In Cartridge
Nominal Size
10
Number of Ports/Ways
2-Port
Port Type
SAE
Seal Material
Buna-N
Series
RV1-10 Series
Style
Poppet

Product Questions & Answers (2)

Sign In Hover me Please sign in to submit a question
Question by: Brett E on Dec 6, 2025, 9:46 AM
what's the max flow this thing can handle through the port, and does the 30 L/min rating apply to the whole system or just at the valve itself?
Answer by: Customer Support on Dec 7, 2025, 12:23 PM
The 30 litres per minute figure is the flow rate through the 3/8" port on this valve. The broader system capacity is rated up to 300 L/min (80 USgpm), so the valve can operate within a much larger circuit without being the bottleneck. Pressure-wise, it holds up to 350 bar (5,000 psi), which covers most demanding mobile and industrial setups. That combination is part of why this series gets used on things like harvesters and refuse haulers where you need reliable pressure control under real working conditions.
Question by: Clint A on Mar 17, 2026, 5:17 PM
Will this handle a flow rate of 25 liters per minute without any trouble?
Answer by: Customer Support on Mar 19, 2026, 11:53 AM
Designed to handle flow rates up to 30 liters per minute, this valve should operate without issues at 25 liters per minute.
