VICKERS MRV6-10-0-6T

Ask A Question

Description & Features

The Vickers MRV6-10-0-6T is a 4-way, 3-position directional control valve designed for demanding mobile and industrial applications, including use in harvesters and refuse haulers. This Vickers valve offers reliable and economical performance in a compact design. It provides maximum flexibility while occupying minimal space.

This valve is rated to 350 bar (5000 psi) and a flow rate of 11 liters per minute (approximately 3 US GPM). It features a 3/8" port size.

SKU: 02-183150

Supplier Part Number (MPN): 02-183150

Specifications

Brand
Vickers by Danfoss
Actuator Type
Direct Acting
Adjustment Type
No Operator
Body Material
Aluminum
Cavity
C-10-4
Detent Option
Without Detent
Dimensions
3 in L x 2 in W x 4.64 in H
Domestic/Import
Import
Function
Manual Semi-Rotary Valve
Housing
With Housing
Installation Type
Screw-In Cartridge
Language
English
Number of Ports/Ways
4-Port, 4-Way
Number of Positions
3
Port Type
SAE
Seal Material
Buna-N
Series
MRV6-10 Series

Product Questions & Answers (2)

Question by: Lance T on Mar 7, 2026, 12:35 PM
So this is a 4-way valve, meaning it's got four ports, right? Just want to make sure I'm understanding that correctly.
Answer by: Customer Support on Mar 9, 2026, 6:04 AM
Correct. It's configured as a 4-way, 3-position directional control valve, suitable for directing flow between four ports in your hydraulic system.
Question by: Gene P on Mar 2, 2026, 6:32 AM
Running a refuse hauler and need a 4-way, 3-position directional control valve that ain't gonna eat up a ton of space. This MRV6-10-0-6T rated for that kind of work?
Answer by: Customer Support on Mar 4, 2026, 6:35 AM
Refuse haulers are one of the exact applications this valve was built around. It handles up to 350 bar (5000 psi) and flows at 11 liters per minute, which works out to roughly 3 US GPM. The 3/8" port size keeps the footprint compact, so it fits where space is tight without giving up pressure capacity.
