Vickers RV5 10VF 8H 20/15

Ask A Question

Description & Features

Designed for demanding mobile and industrial environments, the Vickers RV5 10VF 8H 20/15 is a spool-style pressure control valve rated to 350 bar (5000 psi) with a flow capacity of 114 litres per minute through a 1/2" port. Its compact form factor makes it well suited for installations where space is limited without sacrificing performance range.

Part of the Vickers RV5-10 series from Danfoss/Eaton, this valve is commonly deployed in harvesters, refuse haulers, and a range of mobile and industrial hydraulic circuits. The spool design supports reliable, consistent pressure regulation, and the series is recognized for balancing economic value with technical capability across varied duty cycles.

SKU: 02-198522

Supplier Part Number (MPN): 02-198522

Alternate Part Numbers: C1FJ71

Specifications

Brand
Vickers by Danfoss
Actuator Type
Pilot Operated
Adjustment Type
Factory Set
Body Material
Steel
Cavity
C-10-2
Connection Type
SAE
Dimensions
2.5 in L x 1.74 in W x 5.63 in H
Domestic/Import
Import
End Type
SAE
Housing
With Housing
Installation Type
Screw-In Cartridge
Nominal Size
10
Number of Ports/Ways
2-Port
Port Type
SAE
Seal Material
FKM
Series
RV5-10 Series
Style
Spool

Product Questions & Answers (1)

Question by: Travis C on Aug 29, 2025, 3:09 PM
Got a harvester sitting idle because the pressure control valve gave out, does this RV5 unit fit that kind of application or is it more of an industrial shop part?
Answer by: Customer Support on Aug 31, 2025, 12:10 PM
Harvesters are actually one of the listed applications for this valve, so you're right in the wheelhouse it was built for. It handles up to 350 bar (5000 psi) and flows 114 litres per minute through a 1/2" port, which gives it enough range for the kind of demanding cycles you'd see in mobile harvest equipment. The spool-style design keeps pressure regulation consistent, and the compact build means it fits into tighter installations where you don't have a lot of room to work with.
