VICKERS PTS9-16-U-0000-050-00

Description & Features

Designed for demanding mobile and industrial environments, the Vickers PTS9-16-U-0000-050-00 is a spool-style directional control valve rated for up to 350 bar (5,000 psi) and flows to 265 L/min (70 USgpm). With a working flow rate of 151 litres per minute, it suits high-pressure circuit control across a wide range of applications.

Part of the Vickers by Danfoss/Eaton PTS9-16 Series, this valve is well suited for use in harvesters, refuse haulers, and both mobile and stationary industrial systems. Its compact form factor supports flexible installation where space is constrained, and the economical design makes it a practical choice for equipment builders and system integrators managing size and weight requirements.

SKU: 02-198928

Supplier Part Number (MPN): 02-198928

Specifications

Actuator Type Hydraulic, Pilot Operated	Dimensions 4-1/2 in L x 1-1/2 in W x 1-1/2 in H	Domestic/Import Import	Installation Type Screw-In Cartridge	Language English	Number of Ports/Ways 3-Way	Seal Material Buna-N	Series PTS9-16 Series	Style Spool

Product Questions & Answers (1)

Question by: Cheryl E on Jul 23, 2025, 8:43 PM

Got a harvester that's been chewing through directional valves and I need something that'll hold up at high pressure. This one rated for 5000 psi?

Answer by: Customer Support on Jul 25, 2025, 3:33 PM

350 bar which works out to right around 5,000 psi, so it's built for exactly that kind of high-pressure work. The PTS9-16 series was put together with mobile equipment like harvesters in mind, so that application fits well within what this valve is meant to handle.
