DG3V32AT7B60

Description & Features

Designed for machine tool and broader industrial use, the DG3V32AT7B60 is a single-stage directional control valve from Vickers by Danfoss Power Solutions, part of the well-established DG3V-3 series. It supports three- or four-way directional control and is rated for flow up to 151 litres per minute, making it well suited to mid-range hydraulic circuit requirements.

Buna-N seals provide reliable fluid compatibility across common hydraulic media. The valve mounts easily on industry-standard surfaces, simplifying integration into existing hydraulic systems. With thousands of models available within the DG3V series, this product sits within a broad platform designed to cover a wide range of directional control configurations and application demands.

SKU: 02-308670

Supplier Part Number (MPN): 02-308670

Specifications

Actuator Type Hydraulic	Connector Type ISO 4401-03 Plug	Dimensions 3.89 in L x 1.88 in W x 2.01 in H	Installation Type Subplate/Manifold	Media Petroleum Oil	Number of Positions 3	Number of Stages 1	Performance High	Seal Material FKM	Series DG3V-3 Series

Product Questions & Answers (1)

Question by: Chad T on Apr 6, 2026, 7:18 AM

Flow rate on this one is listed at 151 litres per minute, that enough to handle mid-range hydraulic circuits without choking things out?

Answer by: Customer Support on Apr 7, 2026, 6:38 PM

For mid-range hydraulic work, 151 litres per minute gives you solid headroom. That rating puts it well within the range for machine tool applications and a good number of general industrial setups where you're not pushing extreme volumes. If your circuit stays within that ceiling, you won't be fighting flow restriction at the valve.
