VICKERS DG5V8H6C2EMUA10

Ask A Question

Description & Features

Designed to perform in demanding industrial environments, the VICKERS DG5V8H6C2EMUA10 is a versatile directional control valve suitable for numerous applications, including die casting, machine tooling, marine, and turbine control. With a robust flow rate of 700 liters per minute, it ensures efficient fluid management across various systems. This valve features three- or four-way directional control, making it adaptable to diverse operational needs.

Constructed with Buna-N seal material, the VICKERS DG5V8H6C2EMUA10 is built for durability and reliability. Its compatibility with industry-standard mounting surfaces facilitates easy integration into existing setups. With the backing of Vickers' reputation for quality, this valve is available in thousands of models to meet specific application requirements.

SKU: 02-399076

Supplier Part Number (MPN): 02-399076

Specifications

Brand
Vickers by Danfoss
Actuator Type
Solenoid, Pilot Operated
Design
10 Series
Dimensions
10.45 in L x 4.67 in W x 9.36 in H
Domestic/Import
Domestic
Ext Pilot Pressure
External
Gauge Port Thread
7/16-20 UNF, SAE Thread
Indicator Light
Without Indicator Light
Int Pilot Drain
External
Manual Override
Plain
Media
Petroleum Oil
Number of Stages
2
Performance
High
Seal Material
Buna-N
Series
DG5V-8 10 Series
Spool Control
Pilot Choke Adjustment
Spool Position Monitor
Without Spool Position Monitor
Spool Type
Spool 6
Spring Arrangement
Spring Centered
Surge Suppressor Damper
Without Surge Suppressor Damper
Valve Mount Type
Subplate/Manifold

Product Questions & Answers (1)

Question by: Ross H on Nov 14, 2025, 5:27 PM
flow rate on this thing is listed at 700 liters per minute, is that enough for press and die casting work or is it right on the edge?
Answer by: Customer Support on Nov 16, 2025, 6:25 AM
For press and die casting applications, 700 liters per minute is a solid capacity. Die casting and press systems can demand high flow during rapid cycling, and this valve was built with exactly those environments in mind. It's also rated for primary metal, marine, turbine control, and machine tool use, so it's not a lightweight unit by any stretch. If your system runs within that flow range, you're in good shape.
