main product photo

DANFOSS / EATON-XLS Series, Spool Valve

Ask A Question

Description & Features

Designed for demanding mobile applications, the Danfoss / Eaton XLS Series, Spool Valve is a low-speed Geroler motor built to deliver high torque output in compact equipment. With a torque rating of 473 Nm and a maximum flow rate of 57 litres per minute, it suits hydraulic systems where controlled, high-force rotation at low speeds is required.

Cast iron construction supports durability under sustained load conditions. The disc valve mechanism is engineered for consistent speed performance, while the spool valve configuration contributes to reliable commutation across the operating range. Typical applications include aerial work platforms and turf care equipment, environments where smooth low-speed torque and dependable response are priorities. The Xcel sub-brand positions this motor as a feature-rich option within the Char-Lynn product family.

SKU: 036-0266-002

Supplier Part Number (MPN): 036-0266-002

Specifications

Brand
Danfoss
Bearing Type
Hydrodynamic Journal
Check Valve Function
With Check Valve Function
Color
Black
Design Code
B
Dimensions
8.27 in L x 5.12 in W x 3.7 in H
Drain Port Dimension
7/16-20 UNF-2B SAE O-ring
Frame Size
395
Housing Material
Iron
Mounting Type
2-Bolt Flanged
Orbital Gearwheel Set
Standard
Orbital Gearwheel Set Type
Geroler
Painted
With Painted
Port Location
Side, Staggered
Port Type
UNF-2B, SAE O-ring
Seal Material
NBR
Series
XLS Series
Shaft Size
1 in Dia
Shaft Type
Splined
Valve Type
Spool

Product Questions & Answers (1)

Question by: Ronnie W on Jul 14, 2025, 9:01 PM
Got a turf machine that's been eating through motors and I need something that'll hold up to low-speed high-torque work without falling apart on me. This the right kind of unit for that?
Answer by: Customer Support on Jul 16, 2025, 9:04 AM
Cast iron housing and a 473 Nm torque rating put this motor in solid shape for exactly that kind of demand. The Geroler design is built around low-speed torque delivery, so it's not just tolerating that workload, it's what the motor is optimized for. The disc valve keeps speed consistent even when torque loads shift, which helps cut down on the wear patterns that tend to shorten motor life in turf equipment.
