main product photo

F Din X M Din Reducer

Ask A Question

Description & Features

Designed for reducing between two DIN tube connections, this straight steel adapter connects a female M16 x 1.5 (L10) DIN fitting to a male M12 x 1.5 (L06) DIN fitting in a single inline body. The F Din X M Din Reducer is manufactured by Adaptall and suits hydraulic lines where a step-down in DIN tube size is required without changing connection style.

Constructed from steel, the adapter measures 25mm on the female side (Ch1 width 14mm) and 31mm on the male side (Ch2 width 19mm). The straight configuration keeps routing clean and predictable in tight installations. Its all-steel construction makes it suitable for demanding hydraulic service environments.

SKU: 5315L-10-06

Supplier Part Number (MPN): 5315L-10-06

Specifications

Brand
adapt-all
Connection Size 2
6 mm
Connection Type
Female Metric Swivel, Male Metric
Connection Type 1
Female DIN 24 deg Tube Swivel
Connection Type 2
Male DIN Tube
Dimension Standards
DIN 2353
Dimensions
33 mm L
Finish
Zinc-Plated
Fitting Type
Reducer
Material
Steel
Material Construction
Carbon Steel
Series
5315 Series
Thread Size
M16x1.5 x M12x1.5

Similar Products

Model Number Connection Size 1 Connection Size 2 Thread Size Hex Size Price Action
F Din X M Din Reducer

5315L-08-06

8 mm

6 mm

M14x1.5 x M12x1.5

F Din X M Din Reducer

5315L-10-08

8 mm

M16x1.5 x M14x1.5

F Din X M Din Reducer

5315L-12-08

L12

8 mm

M18x1.5 x M14x1.5

17 x 22 mm

F Din X M Din Reducer

5315L-15-06

L15

6 mm

M22x1.5 x M12x1.5

F Din X M Din Reducer

5315L-15-08

L15

8 mm

M22x1.5 x M14x1.5

F Din X M Din Reducer

5315L-15-12

L15

12 mm

M22x1.5 x M18x1.5

F Din X M Din Reducer

5315L-18-12

18 mm

12 mm

M26x1.5 x M18x1.5

F Din X M Din Reducer

5315L-18-15

18 mm

15 mm

M26x1.5 x M22x1.5

F Din X M Din Reducer

5315L-22-15

L22

15 mm

M30x2 x M22x1.5

F Din X M Din Reducer

5315L-22-18

L22

18 mm

M30x2 x M26x1.5

F Din X M Din Reducer

5315L-28-18

L28

18 mm

M36x2 x M26x1-1/2

36 mm, 46 mm

F Din X M Din Reducer

5315L-28-22

L28

22 mm

M36x2 x M30x2

36 mm, 46 mm

F Din X M Din Reducer

5315L-35-22

22 mm

M45x2 x M30x2

F Din X M Din Reducer

5315L-42-35

L42

35 mm

M52x2 x M45x2

50 mm, 60 mm

Product Questions & Answers (2)

Question by: Neil R on Dec 24, 2025, 11:55 AM
So, this thing reduces DIN tube sizes, right? How much smaller does it go?
Answer by: Customer Support on Dec 25, 2025, 3:57 PM
That's right. Specifically, this reducer adapts from a female M16 x 1.5 (L10) DIN fitting down to a male M12 x 1.5 (L06) DIN fitting.
Question by: Shawn R on Jun 5, 2025, 4:37 PM
got a hose end that’s M16 x 1.5 DIN (L10) but the line I’m tying into is M12 x 1.5 (L06). Is this the right reducer?
Answer by: Customer Support on Jun 7, 2025, 12:35 PM
For stepping down between those two DIN tube sizes, it matches that exact combo. Side 1 is a female M16 x 1.5 (L10) DIN tube connection, and side 2 is a male M12 x 1.5 (L06) DIN tube connection, all in a straight inline adapter.
