1500M Series Gear Motor, 1.18 cu in/rev, 2-Bolt SAE A Mounting Flange, 5/8 St.Keyed x 2.00 Long Shaft, 3/4 NPT Rear Ports, Bi-Rot.

Ask A Question

Description & Features

Built for demanding hydraulic applications, this Continental Hydraulics Inc unit features heavy-duty iron castings rated to 2000 PSI and a pressure-lubricated roller bearing design that tolerates contamination better than standard gear motors while remaining fully repairable. Deflecting pressure-balanced wear plates help sustain volumetric efficiency, and the mechanical face seal supports high back pressures without requiring a case drain.

The 1500M Series Gear Motor, 1.18 cu in/rev, 2-Bolt SAE A Mounting Flange, 5/8 St.Keyed x 2.00 Long Shaft, 3/4 NPT Rear Ports, Bi-Rot. delivers a displacement of 1.18 cu in/rev with a rated flow of 8.3 GPM and a maximum speed of 3600 RPM. The 2-bolt SAE A mounting flange and rear 3/4 NPT ports support straightforward integration, while bidirectional rotation adds installation flexibility. A shielded outboard bearing allows limited side loading on the input shaft. Maximum system temperature is 180°F, and 10-micron absolute filtration is recommended for optimal motor life.

SKU: 1510MC3E1BB

Supplier Part Number (MPN): 1510MC3E1BB

Alternate Part Numbers: 20012303, 51053135, C1AK83

Specifications

Brand
Hydreco
Bearing Type
Roller
Dimensions
4.78 in L x 4.19 in W x 5.26 in H
grp Recommended Filtration
10 um Absolute For Maximum Motor Life
Housing Material
Iron
Inlet Type
NPT
Model
1510M
Mounting Type
SAE A 2-Bolt Flange
Outlet Type
NPT
Rotation
Reversible
Series
1500 Series
Shaft IO
5/8 in Straight Keyed x 2 in Long

Similar Products

Model Number Displacement Mount Shaft Ports Features Price Action
1500M Series Gear Motor, 0.74 cu in/rev, 2-Bolt SAE A Mounting Flange, 5/8 St.Keyed x 2.00 Long Shaft, 3/4 NPT Rear Ports, Bi-Rot.

1506MC3E1BB 1500M Series Gear Motor

0.738

2-Bolt SAE A

5/8 St.Keyed x 2.00 Long

3/4 NPT Rear Ports

Bi-Rotational, Shielded Outboard Bearing

1500M Series Gear Motor, 1.47 cu in/rev, 2-Bolt SAE A Mounting Flange, 5/8 St.Keyed x 2.00 Long Shaft, 3/4 NPT Rear Ports, Bi-Rot.

1512MC3E1BB 1500M Series Gear Motor

1.467

2-Bolt SAE A

5/8 St.Keyed x 2.00 Long

3/4 NPT Rear Ports

Bi-Rotational, Shielded Outboard Bearing

Product Questions & Answers (3)

Question by: Dale S on Aug 13, 2025, 8:44 PM
does this motor run both directions or is it set one way from the factory?
Answer by: Customer Support on Aug 15, 2025, 9:25 AM
Bi-rotational right out of the box. You can run it clockwise or counterclockwise without any modification, which makes it a lot more flexible when you're fitting it into an existing system and don't want to reconfigure your hydraulic connections.
Question by: Judy T on Feb 11, 2026, 6:33 AM
What kind of fluid should I be running in this thing? I use all sorts.
Answer by: Customer Support on Feb 13, 2026, 6:52 AM
Ratings are based on using anti-wear hydraulic fluid. If you're planning on using other fluids, it's best to get in touch with us so we can advise you.
Question by: Janice S on Jan 1, 2026, 3:48 PM
got a 2-bolt SAE A mount and rear ports, will this motor bolt up and hook up without me having to get weird adapters?
Answer by: Customer Support on Jan 3, 2026, 6:43 AM
It uses a 2-bolt SAE A mounting flange and 3/4 NPT rear ports, so it matches equipment set up for that mount pattern and those port threads. The shaft is a 5/8 straight keyed shaft that sticks out 2.00 inches, so you will want your coupling or hub sized for a 5/8 keyed shaft.
