24MP-24FPS 45

Description & Features

Tompkins Industries offers a reliable solution with the 24MP-24FPS 45 hydraulic fitting, engineered for efficiency in industrial applications. This robust fitting features a 45-degree swivel design, facilitating smooth connections and adaptations in hydraulic systems. Its precision-crafted construction ensures durability under demanding conditions, making it an ideal choice for maintaining system integrity and performance.

The 24MP-24FPS 45 fitting has been designed with compatibility and ease of use in mind, supporting seamless integration into a variety of setups. The swivel feature allows for flexible connections, while the high-quality materials used in its construction provide long-lasting resilience against wear and tear. This fitting is compatible with multiple configurations, offering versatility across different industrial scenarios.

SKU: 1503-24-24

Supplier Part Number (MPN): 1503-24-24-FG

Alternate Part Numbers: A2049-24-24S, MI-00321255, MINO-00028F66053

Specifications

Brand
BRENNAN
Connection Size 1
1-1/2 in
Connection Size 2
1-1/2 in
Connection Type
FNPSM Swivel, MNPT
Connection Type 1
Male SAE 30 deg NPTF
Connection Type 2
SAE FNPSM Swivel
Dimension Standards
SAE J476, SAE J514
Finish
Trivalent Zinc-Plated
Fitting Type
45 deg Elbow
Hex Size
2-1/8 in
Material
Steel
Material Construction
AISI C1045 Steel
Series
1503-FG Series
Thread Size
1-1/2-11-1/2

Similar Products

Model Number Connection Size 1 Connection Size 2 Thread Size Hex Size Price Action
16MP-20FPS 45 DEG Elbow

1503-16-20-FG

1-1/4 in

1 in

1-1/4-11-1/2 x 1-11-1/2

1-7/8 in

#4 MP X #2 FP SWIVEL 45*

1503-04-02-FG

1/4 in

1/8 in

1/4-18 x 1/8-27

0.563 in

#4 MP X #4 FP Swivel 45*

1503-04-04-FG

1/4 in

1/4 in

1/4-18

11/16 in

#6 MP X #6 FP Swivel 45*

1503-06-06-FG

3/8 in

3/8 in

3/8-18

7/8 in

ADAPTER

1503-06-08

3/8 in

1/2 in

1/2-14 x 3/8-18

1 x 1 in

#8 MP X #4 FP SWIVEL 45*

1503-08-04-FG

1/2 in

1/4 in

1/2-14 x 1/4-18

11/16 in

#8 MP X #6 FP SWIVEL 45*

1503-08-06

1/2 in

3/8 in

1/2-14 x 3/8-18

7/8 in

#8 MP X #8 FP Swivel 45*

1503-08-08-FG

1/2 in

1/2 in

1/2-14

1 x 1 in

#12 MP X #12 FP Swivel 45*

1503-12-12-FG

3/4 in

3/4 in

3/4-14

1-1/4

#16 MP X #12 FP SWIVEL 45*

1503-16-12

1 in

3/4 in

1-11-1/2 x 3/4-14

1-1/4

#16 MP X #16 FP Swivel 45*

1503-16-16-FG

1 in

1 in

1-11-1/2

1-1/2 in

1503-20-16-FG

1503-20-16-FG

1-1/4 in

1 in

1-1/4-11-1/2 x 1-11-1/2

1-1/2 in

#20 MP X #20 FP SWIVEL 45*

1503-20-20

1-1/4 in

1-1/4 in

1-1/4-11-1/2

1-7/8 in
