Danfoss / Eaton PG ASY (CHG AZ)

Description & Features

A carbon steel straight adapter designed for hydraulic system connections, the Danfoss / Eaton PG ASY (CHG AZ) features a 3/4-inch male UN thread end and a product width of 0.94 inches. Dura-Kote plating provides corrosion resistance across a wide service range, with a rated minimum working temperature of -65°F supporting use in demanding environmental conditions.

Manufactured to exceed SAE pressure standards, this adapter offers design flexibility within a broad range of compatible configurations. The male UN thread end type suits a variety of industrial hydraulic circuit connections where reliable, pressure-rated straight adapter fittings are required.

SKU: 16224-05

Supplier Part Number (MPN): 16224-05

Specifications

Brand Danfoss	Connection Size 1 3/4 in	Dimensions 0.94 in W	Finish Dura-Kote™	Fitting Type Plug	Material Steel	Material Construction Carbon Steel	Operating Temperature -65 to 400 deg F	Series 16224 Series

Product Questions & Answers (2)

Question by: Pete M on Aug 5, 2025, 6:15 PM

Will this adapter work with standard hydraulic fittings, or are there specific ones I need to use?

Answer by: Customer Support on Aug 7, 2025, 1:47 PM

It's designed for use with various industrial hydraulic circuit connections that require a reliable, pressure-rated straight adapter fitting, and it exceeds SAE pressure standards for higher operating pressures.

Question by: Rusty H on Jul 10, 2025, 9:26 PM

What kind of coating does this adapter have, and will it hold up running outdoors year-round?

Answer by: Customer Support on Jul 12, 2025, 8:12 PM

Dura-Kote plating covers the exterior, which is specifically built to fight corrosion over long service life. Carbon steel is the base material, so the plating is doing real work there. For outdoor use across seasons, that combination handles it well, and the adapter is rated down to -65°F on the low end, so cold weather exposure is not a concern.
