MDL143AA07AA000000000AB00B

Ask A Question

Description & Features

A low-speed, high-torque hydraulic motor built for demanding mobile and industrial applications, the MDL143AA07AA000000000AB00B is part of the Char-Lynn Delta Series Disc Geroler line from Danfoss/Eaton. Constructed from cast iron, it delivers a torque rating of 651 Nm and supports flow rates up to 75 litres per minute, making it well suited for scissor lifts, boom lifts, industrial sweepers, and mowers.

The Delta Series Disc Geroler design is recognized for its low pressure drop characteristics and high efficiency, which contributes to measurable energy savings in mobile hydraulic circuits. Available in standard, wheel, and bearingless configurations, this motor accommodates a range of mounting and drive requirements without significant design modification.

SKU: 184-0196-002

Supplier Part Number (MPN): 184-0196-002

Alternate Part Numbers: 184-0196, MDL143AA07AA000000000AB00B

Specifications

Brand
Danfoss
Bearing Type
Needle Roller
Check Valve Function
Without Check Valve Function
Color
Black
Design Code
B
Dimensions
7.17 in L x 5.35 in W x 5.35 in H
Frame Size
235
Housing Material
Iron
Mounting Type
4-Bolt Wheel Flanged
Orbital Gearwheel Set
Standard
Orbital Gearwheel Set Type
Geroler
Paint Information
Low Gloss Black Primer
Painted
With Painted
Port Location
Side, Aligned
Port Type
UNF-2B, SAE O-ring
Rotation Direction
Counterclockwise
Seal Material
NBR
Series
Delta Series
Shaft Type
Straight Rectangular Keyed
Valve Type
Disc

Product Questions & Answers (1)

Question by: Daryl D on Nov 19, 2025, 12:55 PM
Got a scissor lift that needs a new drive motor and I'm tryin to figure out if this one'll hold up to the job. What kind of torque output are we talking here?
Answer by: Customer Support on Nov 21, 2025, 8:15 AM
For a scissor lift application, 651 Nm is a solid output for a motor this size. That torque rating puts it well within range for the kind of load demand scissor lifts typically put on a drive motor. The cast iron construction adds to the durability side of things, so it's not going to be a lightweight unit that wears out quick under regular use.
