The Danfoss / Eaton DOT Connector is engineered for air brake systems offering durability and reliability. Its Dura-Kote plating delivers superior corrosion resistance ensuring longevity in harsh conditions. Designed to meet higher operating pressures it exceeds SAE standards.
End Type 1 is Push to Connect while End Type 2 features NPTF providing design flexibility with a wide range of styles available.
The product material is brass with a width of 1.06 inches and a minimum working temperature of -40 degrees. This straight adapter has an end size of 0.5 for both connections.
Alternate Part NumberMI-04494596, Alternate Part Number MINO-00015X03591, Alternate Part Number MINO-00925X94000
Application
Air brake systems
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
End Gender 2
13556
End Size 1
0.50
End Size 2
0.50
End Type 1
Push to Connect
End Type 2
NPTF
Features
Dura-Kote plating for superior corrosion resistance|Design flexibility with hundreds of styles to choose from|Higher operating pressures above SAE standards
ICC
Straight Adapters
Language
English
Minimum Working Temperature
-40
Net Pack Quantity Units
EA
NMFC
60
Product Material
Brass
Product Width
1.06
Sub Brand
Weatherhead
Supplier Part Number
1868X12
Product Weight
0.21 lbs
Product Questions & Answers (2)
Question by: Neal H on May 22, 2025, 7:44 AM
Will this here fitting hold up okay for a truck air brake system?
Answer by: Customer Support on May 23, 2025, 9:19 AM
Absolutely. This Eaton DOT connector is purpose-built for air brake systems, meeting and exceeding SAE standards for operating pressure.
Question by: Rusty H on May 5, 2025, 9:26 PM
does this connector work for air brake lines, or is it made for something else altogether?
Answer by: Customer Support on May 7, 2025, 4:53 PM
Air brake systems are exactly what this connector is built for. It combines a push-to-connect end with a 1/2 inch NPTF male thread on the other side, so it bridges the two connection types without adapters or workarounds. The brass body holds up well under the pressure demands those systems put on fittings, and the Dura-Kote plating adds a solid layer of corrosion resistance for trucks and equipment running in rough conditions.
