Aeroquip Fitting (REUS) Other R5

Description & Features

A male inverted flare, 90° short elbow configuration makes this carbon steel reusable hose fitting well suited for hydraulic lines where space constraints require a compact directional change. The Aeroquip Fitting (REUS) Other R5 is designed for -8 hose dash size connections, with a 0.6875-inch end size and a 0.94-inch hex, and carries a package weight of 0.25 lb. The reusable design helps cut assembly times and supports efficient field maintenance without requiring replacement of the full fitting assembly.

Manufactured by Aeroquip by Danfoss/Eaton under the 190235 series, this fitting is built for a wide range of industrial hydraulic applications. Carbon steel construction provides reliable durability in demanding service environments.

SKU: 190235-7-8S

Supplier Part Number (MPN): 190235-7-8S

Alternate Part Numbers: C1AL89

Specifications

Connection Size 1 11/16 in	Connection Size 2 11/16 in	Connection Type Hose, Male SAE Inverted Flared	Connection Type 1 Hose	Connection Type 2 Male SAE 45 deg Inverted Flare	Cut-Off Factor 1.89 in	Dimensions 0.28 in ID	Drop Dimensions 1.73 in	Finish Dura-Kote™	Fitting Type 90 deg Elbow	For Use With FC300, FC321, FC350, FC355 and FC802 Series Hoses	Hex Size 0.69 x 0.94 in	Hose Dash Size 08	Material Steel	Material Construction Carbon Steel	Series 190235 Series	Thread Size 11/16-18

Product Questions & Answers (1)

Question by: Shane B on Apr 29, 2025, 8:37 PM

Is this fitting made to be reused, or is it a one-time deal?

Answer by: Customer Support on May 1, 2025, 10:08 AM

This Aeroquip fitting is designed for reusability, which can save time on assembly and make field maintenance easier. You don't have to replace the whole fitting every time.
