Brennan 16FNPT x C62

A 1-inch FNPT to Code 62 flange adapter, the Brennan 16FNPT x C62 is designed for connecting female NPT threaded lines to SAE Code 62 four-bolt flange ports in high-pressure hydraulic systems. The adapter features a 1-11½ NPTF thread form and a 1-inch pipe size, with an overall length of 3.19 inches and a flange diameter of 2.250 inches.

Manufactured by Brennan Industries under the 1927-62 series, this adapter is suited for demanding hydraulic circuit connections where a secure transition between threaded and flanged interfaces is required. Key dimensions include a 2.75-inch A dimension, 1.093-inch C dimension, and a J bore range of 1.560 to 1.565 inches. The mounting pattern accommodates 7/16-14 threaded fasteners through 0.469-inch drilled holes, with an H dimension of 1.00 inch.

SKU: 1927-62-16-16

Supplier Part Number (MPN): 1927-62-16-16
