2.5PB Series Aluminum Gear Pump, 1.53 cu in/rev, 2-Bolt SAE B Mounting Flange, 7/8 Straight Keyed SAE B Shaft, SAE -16 Side Inlet, SAE -12 Side Outlet, CW Rotation

Description & Features

Designed for mobile and industrial hydraulic circuits requiring reliable fixed-displacement flow, the 2.5PB Series Aluminum Gear Pump, 1.53 cu in/rev, 2-Bolt SAE B Mounting Flange, 7/8 Straight Keyed SAE B Shaft, SAE -16 Side Inlet, SAE -12 Side Outlet, CW Rotation is a single-unit pump from Salami Hydraulics built around a lightweight aluminum housing with a continuous working pressure rating of 3,600 PSI and peak capability up to 4,300 PSI.

At 3,000 RPM, this pump delivers a rated flow of 11.8 GPM through SAE -16 side inlet and SAE -12 side outlet ports. Floating bushings provide axial compensation that maintains high volumetric efficiency across the working pressure range, while DU bearings support high-pressure capability. Standard Buna-N seals cover a temperature range of -4°F to 185°F; Viton seal options extend the upper limit to 230°F. Normal operating viscosity falls between 85 and 297 SUS. Clockwise rotation is standard, and shaft or flange configurations are available to match European, German, and American standards. The pump is also available in multiple-unit combinations with other series sizes.

SKU: 613873732

Supplier Part Number (MPN): 613873732

Alternate Part Numbers: 2.5PB25D-R87S3 PUMP, C1MR67

Specifications

Displacement 1.53	Displacement 1.53	Brand Salami Hydraulics Na Inc	Brand Salami Hydraulics	Pack Size 1.00	UOM EA	Mount 2-Bolt SAE B	Mount 2-Bolt SAE B	Ports SAE -16 Side Inlet, SAE -12 Side Outlet	Ports SAE -16 Side Inlet, SAE -12 Side Outlet	Pressure Rating 3600	Rated Flow 11.80	Rated Flow 11.8	Rotation CW	Shaft 7/8 Straight Keyed SAE B	Shaft 7/8 Straight Keyed SAE B	Speed Rating 3000 RPM	Speed Rating 3000 RPM	Supplier Part Number 613873732	Alternate Part Numbers Alternate Part Number 2.5PB25D-R87S3 PUMP, Alternate Part Number C1MR67	Product Weight 9.02 lbs

Similar Products

Model Number	Displacement	Rated Flow	Mount	Shaft	Ports	Rotation	Pressure Rating	Speed Rating
613871192 2.5PB Series Gear Pump	1.68	13	2-Bolt SAE B	7/8 13T Splined SAE B	SAE -16 Side Inlet, SAE -12 Side Outlet	CW	3600	3000 RPM
613871202 2.5PB Series Gear Pump	1.97	15.3	2-Bolt SAE B	7/8 13T Splined SAE B	SAE -16 Side Inlet, SAE -12 Side Outlet	CW	3300	3000 RPM
613871252 2.5PB Series Gear Pump	1.35	10.5	2-Bolt SAE B	7/8 Straight Keyed SAE B	SAE -12 Side Inlet, SAE -10 Side Outlet	CW	3600	3000 RPM
613871282 2.5PB Series Gear Pump	1.97	15.3	2-Bolt SAE B	7/8 Straight Keyed SAE B	SAE -16 Side Inlet, SAE -12 Side Outlet	CW	3300	3000 RPM
613873722 2.5PB Series Gear Pump	1.53	11.8	2-Bolt SAE B	7/8 13T Splined SAE B	SAE -16 Side Inlet, SAE -12 Side Outlet	CW	3600	3000 RPM
613873732 2.5PB Series Gear Pump	1.53	11.8	2-Bolt SAE B	7/8 Straight Keyed SAE B	SAE -16 Side Inlet, SAE -12 Side Outlet	CW	3600	3000 RPM
613873922 2.5PB Series Gear Pump	1.17	9.1	2-Bolt SAE B	7/8 13T Splined SAE B	SAE -12 Side Inlet, SAE -10 Side Outlet	CW	3600	3000 RPM

Product Questions & Answers (2)

Question by: Lynn A on Mar 3, 2026, 7:20 PM

pump's only rated for clockwise rotation -- can that be swapped out if my setup runs counterclockwise?

Answer by: Customer Support on Mar 5, 2026, 6:18 AM

Rotation can be changed on this pump by reversing the positions of the drive shaft and driven shaft and rotating the front flange. It ships standard with clockwise rotation, so if your system runs the other direction, you'd just need to make that adjustment during installation. No separate pump model required for CCW applications.

Question by: Gary J on Mar 12, 2026, 8:26 AM

Will this pump work okay with regular hydraulic fluid?

Answer by: Customer Support on Mar 13, 2026, 11:08 AM

This Salami pump is rated to work with hydraulic fluids within a viscosity range of 66 to 3635 SUS, with the normal operating range being 85 to 297 SUS.
