2-Ear Pinch Clamp, Zinc Plated Steel, 0.315 - 0.433 Inch Clamping Range, 0.276 Inch Width

Description & Features

The Oetiker 2 ear clamp 3/8 is an ideal solution for securing hoses on air, fluid, gas, and steam lines, especially in industrial environments with heavy vibrating equipment. The clamp boasts a zinc plated steel construction, providing robust corrosion resistance.

The one-piece design ensures a tamper-proof, secure seal without harming the hose. With a clamping range of 0.315 to 0.433 inches and a width of 0.276 inches, this clamp offers reliable performance in demanding applications.

Installation is straightforward: first, close one ear completely. Next, close the second ear until the first ear opens slightly, creating a spring-like effect. This method offers enhanced clamping strength and resilience against pressure, vibration, and shrinkage due to temperature fluctuations or aging. If both ears close completely, a smaller clamp size should be selected.

This clamp is particularly suitable for industrial use, ensuring optimal performance and durability in challenging conditions.

MPN: C1ZZ58

Supplier Part Number: 10100011

Specifications

Clamping Range (in) 0.315 - 0.433	Brand Oetiker Inc.	Brand Oetiker	Pack Size 1.00	UOM EA	Materials Zinc Plated Steel	Nominal Size 0.38	Supplier Part Number 10100011	Product Weight 0.03 lbs	Alternate Part Numbers Alternate Part Number C1ZZ58, Alternate Part Number MI-01555253, Alternate Part Number MINO-00691J50940

Similar Products

Model Number	Materials	Nominal Size	Clamping Range (in)	Width (in)
10100008 2-Ear Pinch Clamp	Zinc Plated Steel	0.3125	0.276 - 0.354	0.276
10100011 2-Ear Pinch Clamp	Zinc Plated Steel	0.375	0.315 - 0.433	0.276
10100016 2-Ear Pinch Clamp	Zinc Plated Steel	0.5	0.433 - 0.512	0.276
10100019 2-Ear Pinch Clamp	Zinc Plated Steel	0.5625	0.512 - 0.592	0.295
10100024 2-Ear Pinch Clamp	Zinc Plated Steel	0.625	0.591 - 0.708	0.315
10100027 2-Ear Pinch Clamp	Zinc Plated Steel	0.75	0.669 - 0.787	0.335
10100030 2-Ear Pinch Clamp	Zinc Plated Steel	0.875	0.787 - 0.905	0.354
10100032 2-Ear Pinch Clamp	Zinc Plated Steel	0.9375	0.866 - 0.984	0.394
15100007 2-Ear Pinch Clamp	Stainless	0.5625	0.512 - 0.592	0.295
15100009 2-Ear Pinch Clamp	Stainless	0.625	0.591 - 0.708	0.315
15100010 2-Ear Pinch Clamp	Stainless	0.75	0.669 - 0.787	0.335
15100012 2-Ear Pinch Clamp	Stainless	0.875	0.787 - 0.905	0.354
15100023 2-Ear Pinch Clamp	Stainless	0.375	0.315 - 0.433	0.276

Product Questions & Answers (3)

Question by: Bobby B on Apr 10, 2025, 12:47 PM

got a hose that measures right around 3/8, is this clamp gonna fit or am i pushing it?

Answer by: Customer Support on Apr 12, 2025, 8:47 AM

Go by the clamping range, not the “3/8” nickname. This one clamps from 0.315 to 0.433 inch, so it works as long as your hose outside diameter where the clamp sits falls in that window.

Question by: Tammy W on May 28, 2025, 7:10 PM

Will these clamps hold up okay on steam lines, or should I be looking at something else?

Answer by: Customer Support on May 30, 2025, 3:02 PM

These Oetiker 2-ear clamps are indeed suited for steam lines, as well as air, fluid, and gas lines, especially in industrial settings where there's a lot of vibration. The zinc plated steel construction provides good corrosion resistance for those applications.

Question by: Warren B on Jan 22, 2026, 9:55 PM

what's the right way to install one of these 2-ear clamps? i always just squeeze both ears down at the same time but somebody told me that's not how you're supposed to do it

Answer by: Customer Support on Jan 24, 2026, 9:28 PM

Your coworker's right on that one. Close the first ear all the way, then work the second ear down until the first ear opens back up just a little, roughly 1/16 of an inch. That slight gap is what gives the clamp its holding strength. It creates a spring-like tension that helps the clamp resist pressure, vibration, and hose shrinkage over time. If you close both ears completely flat, you've likely got too big a clamp for the job and should move down to the next smaller size.
