main product photo

2000 Series Geroler Motor, 11.90 cu in/rev, 2 Bolt SAE A Mounting Flange, 1-1/4 in. Straight Keyed Shaft, 7/8-14 St.Thd. O-Ring Ports,

Ask A Question

Description & Features

The Danfoss / Eaton Char-Lynn 2000 Series Disc Geroler Standard motor is designed for applications such as swing motors brush cutters mowers and harvesting equipment. It offers a displacement of 11.90 cu in/rev ensuring optimal performance in demanding environments. Featuring a 2 Bolt SAE A mounting flange this motor provides reliable and secure installation.

The motor is equipped with a 1-1/4 in. straight keyed shaft and 7/8-14 St.Thd. O-Ring ports. Operating at a maximum case pressure of 2000 PSI it requires premium quality anti-wear type hydraulic fluid. The Geroler motor configuration delivers high efficiency and energy savings with the lowest pressure drop in the industry.

It operates with a maximum temperature of 180 F and has a recommended fluid viscosity range of 100-200 SUS for maximum efficiency. For extended motor life a break-in period of approximately one hour at 30% of rated pressure is recommended before full load application.

Features include standard wheel or bearingless configurations making it adaptable for various industrial needs. Adherence to ISO Cleanliness Code level 18/13 is recommended for optimal filtration.

MPN: 104-1026-006

Specifications

Application
Swing motor, Brush Cutters & mowers, Harvesting equipment
Design Code
6
Displacement
11.90
Displacement
11.9
Brand
Danfoss Power Solutions II (Char-Lynn)
Brand
Char-Lynn
Pack Size
1.00
UOM
EA
Features
Standard, wheel or bearingless configurations|Lowest pressure drop motor in the industry|Highly-efficient Geroler motor provides energy savings
Identification
None
Mount
2 Bolt SAE A
Mount
2 Bolt SAE A
Port Type
.875-14 UNF-2B SAE O-Ring Ports - Staggered Ports
Ports
7/8-14 St.Thd. O-Ring
Ports
7/8-14 St.Thd. O-Ring
Shaft
1-1/4 in. Straight Keyed
Shaft
1-1/4 in. Straight Keyed
Supplier Part Number
104-1026-006
Torque Rating
540 newton metre
Torque Rating
540 newton metre
Valve Options
None
Alternate Part Numbers
Alternate Part Number 104-1026-006, Alternate Part Number C1AH16, Alternate Part Number MINO-00162H28871
Product Weight
25.25 lbs
