main product photo

2000 Series Geroler Motor, 6.20 cu in/rev, 2 Bolt SAE A Mounting Flange, 1 in. Straight Keyed Shaft, 7/8-14 St.Thd. O-Ring Ports, Low Gloss Black Paint

Ask A Question

Description & Features

The 2000 Series Geroler Motor delivers reliable performance for swing motors brush cutters mowers and harvesting equipment. With a displacement of 6.20 cu in/rev it features a 2-bolt SAE A mounting flange and a 1-inch straight keyed shaft ensuring secure and versatile installation. O-Ring ports with 7/8-14 St.Thd provide excellent sealing capabilities.

Noted for being the industry leader in low-pressure drop motors the Char-Lynn Hydraulic Motor variant ensures maximum energy efficiency. Designed to operate efficiently within a fluid viscosity range from 100 to 200 SUS it also supports a maximum case pressure of 2000 PSI without an external case drain. For better longevity it is recommended to run the motor at 30% of rated pressure for an hour during break-in.

The unit's low gloss black paint and integral O-ring ports make it both robust and easy to maintain. It operates efficiently at a maximum temperature of 180F and follows ISO cleanliness level 18/13 for filtration standards demanding premium quality anti-wear hydraulic fluid.

MPN: 104-1671-006

Supplier Part Number: 104-1671

Specifications

Application
Swing motor, Brush Cutters & mowers, Harvesting equipment
Design Code
6
Displacement
6.20
Displacement
6.2
Brand
Danfoss Power Solutions II (Char-Lynn)
Brand
Char-Lynn
Pack Size
1.00
UOM
EA
Features
Standard, wheel or bearingless configurations|Lowest pressure drop motor in the industry|Highly-efficient Geroler motor provides energy savings
Identification
None
Mount
2 Bolt SAE A
Mount
2 Bolt SAE A
Port Type
.875-14 UNF-2B SAE O-Ring Ports - Staggered Ports
Ports
7/8-14 St.Thd. O-Ring
Ports
7/8-14 St.Thd. O-Ring
Shaft
1 in. Straight Keyed
Shaft
1 in. Straight Keyed
Supplier Part Number
104-1671-006
Torque Rating
295 newton metre
Torque Rating
295 newton metre
Valve Options
None
Alternate Part Numbers
Alternate Part Number 104-1671-006, Alternate Part Number C1MH82
Product Weight
24.00 lbs
