Part of the Aeroquip 202208 Series, this Danfoss / Eaton Tube Adapter provides a straight UNF male to hose/tube female connection in carbon steel construction. Designed for use with Freon-compatible refrigerant couplings, it suits hydraulic and fluid systems where reliable straight-line connections are required at temperatures as low as -40°F.
Dura-Kote plating delivers corrosion resistance beyond standard bare-steel fittings, making this adapter well suited for demanding service environments. The 202208 Series is engineered to meet pressure ratings above SAE standards, and the broad range of available styles within the series supports flexible system design. The female end accepts a 0.5556-inch tube connection, with the male end threaded to UNF specification.
SKU: 202208-10-12S
Supplier Part Number (MPN): 202208-10-12S
|
Alternate Part Numbers
MINO-00015X53211
|
Brand
Danfoss Power Solutions (II LLC Aeroquip)
|
Brand
Aeroquip
|
Pack Size
1.00
|
UOM
EA
|
End Gender 1
13554
|
End Size 2
0.56
|
End Type 1
UNF
|
End Type 2
Line/Hose/Tube
|
Features
Dura-Kote plating for superior corrosion resistance|Design flexibility with hundreds of styles to choose from|Higher operating pressures above SAE standards
|
ICC
Straight Adapters
|
Item Type
UNF Male to Hose/Pipe/Tube Female
|
Language
English
|
Minimum Working Temperature
-40
|
Product Material
Carbon Steel
|
Product Width
1.38
|
Sub Brand
Aeroquip
|
Supplier Part Number
202208-10-12S
|
Product Weight
0.19 lbs
|
