main product photo

HANSEN 310 STEEL 3/8 "NPT QDx1/4" PLG

Ask A Question

Description & Features

Designed for use with the Hansen 310 series quick-disconnect coupling system, this steel plug features a 3/8" NPT thread connection and is sized to mate with 1/4" quick-disconnect bodies. Steel construction provides durability in demanding industrial hydraulic and pneumatic applications where reliable sealing and consistent disconnection are required.

The plug configuration allows lines to be capped when disconnected, preventing fluid loss and contamination ingress. Compatible with Hansen 310 series sockets, making it a practical choice for maintenance, tooling, and equipment interchange in industrial environments.

SKU: 22239E

Supplier Part Number (MPN): 22239E

Specifications

Brand
Aeroquip® by Danfoss
Angle Shape
Straight
Connection Size 1
3/8 in
Connection Size 2
1/4 in
Connection Type
MNPT, Push-Fit
Connection Type 1
Male NPTF
Connection Type 2
Push-to-Connect
Dimensions
1.91 in L
Finish
Zinc Trivalent-Plated
Fitting Type
Male Half Coupling
For Use With
Compressed Air, Gases and Liquids
Hex Size
0.63 in
Latch Type
Push/Pull
Material
Steel
Material Construction
Carbon Steel
Maximum Operating Pressure
250 psi
Safety Locking Mechanism
Pin Lock
Seal Material
NBR
Series
310 Series
Thread Size
1/4-18
Valve Type
2-Way

Product Questions & Answers (1)

Question by: Wade P on Jan 3, 2026, 12:46 PM
Will this plug work with any Hansen quick disconnect, or just the 310 series?
Answer by: Customer Support on Jan 4, 2026, 2:41 PM
It's designed specifically for use with the Hansen 310 series quick-disconnect coupling system. Using it with other series might not provide a reliable seal or proper connection.
