DANFOSS / EATON

Ask A Question

Description & Features

Constructed from carbon steel with Dura-Kote plating for corrosion resistance, this straight adapter connects a 1/8" NPTF female port to a 1/2" SAE 37° female swivel end. The fitting is rated to exceed standard SAE operating pressures and is certified to ASME, ASA, and SAE standards, making it a reliable choice for demanding fluid power applications.

The Danfoss / Eaton 2242 Series adapter is suited for use across marine, military, chemical processing, pulp and paper, food and beverage, and offshore drilling environments. Operating temperatures down to -40° are supported, and the swivel design on the SAE 37° end allows for easier installation and alignment in tight or angled configurations.

SKU: 2242-2-5S

Supplier Part Number (MPN): 2242-2-5S

Alternate Part Numbers: C1DV78, MI-08754529, MINO-00015X79010

Specifications

Connection Size 1
5/16 in
Connection Size 2
1/8 in
Connection Type
Female JIC Swivel, FNPT
Connection Type 1
Female SAE 37 deg JIC Flare Swivel
Connection Type 2
Female NPTF
Dimension Standards
SAE 070603/J514
Dimensions
0.87 in L
Finish
Dura-Kote™
Fitting Type
Adapter
Hex Size
5/8 in
Material
Steel
Material Construction
Carbon Steel
nmfc
50
Operating Temperature
-40
Series
2242 Series
Thread Size
1/2-20 x 1/8-27

Product Questions & Answers (2)

Sign In Hover me Please sign in to submit a question
Question by: Merle C on Feb 6, 2026, 5:22 PM
got a line with 1/8 NPTF female on one side and a 37 degree flare swivel on the other. is 2242-2-5S the right straight adapter for that?
Answer by: Customer Support on Feb 8, 2026, 11:29 AM
Match-up wise, 2242-2-5S is a straight adapter built exactly for NPTF female on one end and SAE 37 degree flare female swivel on the other. The listed end sizes are 0.125 on the NPTF side and 0.5 on the SAE 37 side.
Question by: Gene M on Mar 9, 2026, 12:37 PM
what industries is this adapter actually rated for? trying to figure out if it'll hold up in a food processing setup before i pull the trigger on it
Answer by: Customer Support on Mar 11, 2026, 6:33 AM
Carbon steel construction with Dura-Kote plating puts this adapter in good standing for demanding environments. Among the listed applications are food and beverage processing, chemical processing, marine and military use, pulp and paper, and offshore drilling. The corrosion-resistant plating is a big part of what makes it versatile across those sectors, so a food processing environment fits squarely within what this part was built to handle.
