#4 MJIC X #8 FP

Description & Features

Rated to 5,000 PSI dynamic pressure, this straight steel adapter from Brennan Industries connects a #4 Male JIC SAE 37° Flare (7/16-20, per SAE J514) to a #8 Female NPTF (1/2-14, per SAE J476) in a single compact fitting. The #4 MJIC x #8 FP is manufactured from straight steel and carries a Prop 65 warning for California residents.

The mismatched thread sizes make this fitting well suited for hydraulic circuits where a JIC line-side connection must terminate into an NPTF port, bridging two common thread standards without additional adapters. Overall length is 1.680 mm, keeping installation compact within tight assemblies.

SKU: 2405-04-08

Supplier Part Number (MPN): 2405-04-08

Alternate Part Numbers: A2022-8-4S

Specifications

Connection Size 1 1/4 in	Connection Size 2 1/2 in	Connection Type FNPT, Male JIC	Connection Type 1 Male SAE 37 deg JIC Flare	Connection Type 2 Female SAE NPTF	Dimension Standards SAE J514, SAE J476	Dimensions 1.68 in L	Finish Trivalent Zinc-Plated	Fitting Type Adapter	Hex Size 1-1/8 in	Material Steel	Material Construction 12L14/C1045 Steel	Maximum Operating Pressure 5000 psi	Series 2405 Series	Thread 2 Drill Dimensions 0.531 in	Thread B1 Drill Dimensions 0.172 in	Thread B2 Drill Dimensions 0.531 in	Thread Size 7/16-20, 1/2-14

Product Questions & Answers (1)

Question by: Freddie W on Sep 12, 2025, 9:00 PM

So, this adapter goes from a smaller JIC to a bigger NPTF, right? Just wanna make sure I'm understanding that correctly before I order.

Answer by: Customer Support on Sep 14, 2025, 3:59 PM

You've got it. This straight steel adapter connects a #4 Male JIC (SAE 37° Flare) to a #8 Female NPTF, allowing you to adapt between the two thread standards in your hydraulic system. It's a pretty compact way to bridge those different sizes.
