04MJ-06MP 90 DEG ELBOW BRASS

Description & Features

Crafted from high-quality forged brass, the 04MJ-06MP 90 DEG ELBOW BRASS is designed for durability and reliability in industrial applications. This elbow fitting features a unique 90-degree bend, making it ideal for systems requiring a directional change in hydraulic fluid flow. Its robust construction ensures long-lasting performance under demanding conditions.

The fitting incorporates a Male JIC SAE 37 Degree Flare thread on one end, conforming to SAE J514 standards, and a Male NPTF thread on the other, meeting SAE J476 specifications. This combination of threads provides versatile connectivity options, catering to a range of hydraulic setups. With a centerline length of 1.120 mm and an overall length of 1.220 mm, this compact component efficiently utilizes space without compromising functionality.

SKU: 2501-04-06-B

Supplier Part Number (MPN): 2501-04-06-B

Alternate Part Numbers: BR2501-04-06

Specifications

Brand
BRENNAN
Connection Size 1
1/4 in
Connection Size 2
3/8 in
Connection Type
Male JIC, MNPT
Connection Type 1
Male SAE 37 deg JIC Flare
Connection Type 2
Male SAE NPTF
Cubic Inch Space L x W x H Dimensions
1.788 cu-in
Dimension Standards
SAE J514, SAE J476
Dimensions
1.22 in L
Finish
Natural
Fitting Type
90 deg Elbow
Hex Size
3/4 in
l Dimensions
1.22 in
Material
Brass
Material Construction
UNS CA377 Brass
Series
2501-FG Series
Thread 2 Drill Dimensions
0.406 in
Thread B1 Drill Dimensions
0.172 in
Thread B2 Drill Dimensions
0.406 in
Thread Size
7/16-20 x 3/8-18

Similar Products

Model Number Connection Size 1 Connection Size 2 Price Action
04MJ-02MP 90 ELB BRASS

2501-04-02-B

1/4 in

1/8 in

04MJ-04MP 90 ELB BRASS

2501-04-04-B

1/4 in

1/4 in

06MJ-04MP 90 ELB BRASS

2501-06-04-B

3/8 in

1/4 in

06MJ-06MP 90 ELB BRASS

2501-06-06-B

3/8 in

3/8 in

06MJ-08MP 90 DEG ELBOW BRASS

2501-06-08-B

3/8 in

1/2 in

08MJ-04MP 90° ELBOW BRASS

2501-08-04-B

1/2 in

1/4 in

08MJ-06MP 90 ELB BRASS

2501-08-06-B

1/2 in

3/8 in

08MJ-08MP 90 ELB BRASS

2501-08-08-B

1/2 in

1/2 in

08MJ-12MP 90° ELBOW FORGED BRASS

2501-08-12-B

1/2 in

3/4 in

10MJ-06MP 90 ELB BRASS

2501-10-06-B

5/8 in

3/8 in

10MJ-08MP 90 ELB BRASS

2501-10-08-B

5/8 in

1/2 in

BRASS 90DEG #10 MJIC X 3/4

2501-10-12-B

5/8 in

3/4 in

12MJ-08MP 90 ELB BRASS

2501-12-08-B

3/4 in

1/2 in

12MJ-12MP 90 DEG ELBOW BRASS

2501-12-12-B

3/4 in

3/4 in

12MJ-16MP 90 ELBOW BRASS

2501-12-16-B

3/4 in

1 in

16MJ-12MP 90 ELB BRASS

2501-16-12-B

1 in

3/4 in

16MJ-16MP 90 ELB BRASS

2501-16-16-B

1 in

1 in

90 DEG MALE JIC TO MALE NPT

2501-20-20-B

1-1/4 in

1-1/4 in

Product Questions & Answers (1)

Question by: Neal G on Apr 1, 2026, 11:02 AM
Will this elbow fitting work for changing the direction of hydraulic fluid in a tight space?
Answer by: Customer Support on Apr 3, 2026, 7:24 AM
For systems requiring a directional change in hydraulic fluid flow where space is a premium, this elbow fitting is ideal because it has a 90-degree bend. The centerline length is 1.120 mm and the overall length is 1.220 mm, so it should fit comfortably in compact setups.
