Aeroquip CUT Length Hose 50 FEET

Description & Features

Rated to SAE 100R4 and approved by the USCG, MSHA, and Bureau Veritas, this blue elastomer-tube hose is built for suction-line service across hydraulic circuits, lubrication oil systems, gasoline transfer, air, water, and chemical transfer applications. The tube and cover are both elastomer construction, with a reinforcement layer combining helical wire and textile braid for structural integrity under demanding conditions. The conductive construction supports safe handling of fuel and chemical media.

The Aeroquip CUT Length Hose 50 FEET features a 2-ply braid configuration with an embossed lay line and a minimum bend radius of 10 inches at its -24 dash size (2.06-inch width). Rated for service down to -40°F, it is compatible with a range of qualified fittings including OTC, 1A, -40, -48 crimps, and reusable nipple clamps. The cover material provides standard abrasion resistance suited to general industrial environments.

SKU: 2661-24-06000

Supplier Part Number (MPN): 2661-24-06000

Similar Products

Model Number Nominal Size Dash Size Length Price Action
AQP Wire Inserted Suction SAE 100R4 Blue Hose, 2.00 Inch ID, Up To 100.00 PSI

2661-32 AQP Wire Inserted Suction Hose

32

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.25 Inch ID, Up To 200.00 PSI

2661-20 AQP Wire Inserted Suction Hose

20

1 ft

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.00 Inch ID, Up To 250.00 PSI

2661-16 AQP Wire Inserted Suction Hose

1 in

16

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.50 Inch ID, Up To 150.00 PSI

2661-24 AQP Wire Inserted Suction Hose

24

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 0.75 Inch ID, Up To 300.00 PSI

2661-12 AQP Wire Inserted Suction Hose

3/4 in

12

Product Questions & Answers (1)

Question by: Larry E on Jun 11, 2025, 3:45 PM
Is this hose okay for gasoline transfer, or am I gonna have problems?
Answer by: Customer Support on Jun 12, 2025, 8:12 PM
This hose is indeed suitable for gasoline transfer, along with hydraulic circuits, lubrication oil systems, air, water, and certain chemical transfers. It's built with a conductive construction, which adds a safety margin when handling fuel and chemical media.
