main product photo

Aeroquip CUT Length Hose 50 FEET

Ask A Question

Description & Features

Rated to SAE 100R4 and approved by the USCG, MSHA, and Bureau Veritas, this blue elastomer-tube hose is built for suction-line service across hydraulic circuits, lubrication oil systems, gasoline transfer, air, water, and chemical transfer applications. The tube and cover are both elastomer construction, with a reinforcement layer combining helical wire and textile braid for structural integrity under demanding conditions. The conductive construction supports safe handling of fuel and chemical media.

The Aeroquip CUT Length Hose 50 FEET features a 2-ply braid configuration with an embossed lay line and a minimum bend radius of 10 inches at its -24 dash size (2.06-inch width). Rated for service down to -40°F, it is compatible with a range of qualified fittings including OTC, 1A, -40, -48 crimps, and reusable nipple clamps. The cover material provides standard abrasion resistance suited to general industrial environments.

SKU: 2661-24-06000

Supplier Part Number (MPN): 2661-24-06000

Specifications

Abrasion Resistance
29
Application
Suction application for hydraulic, lubrication oils, gasolene,air, water and chemical transfer
Certifications
SAE 100R4|ABS
Color
Blue
Compliances
USCG|MSHA Approved|Bureau Veritas
Conductivity
30
Construction
2-ply braid
Cover Material
Elastomer
Dash Size
-24
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
Features
Maximum durability under harsh operating conditions|Robust construction able to withstand highest pressures|System engineered to extend hose assembly life
ICC
Hoses and Flexible Tubes
Language
English
Lay Line Style
Embossed
Minimum Bend Radius
10
Minimum Bend Radius
10
Minimum Working Temperature
-40
Product Width
2.06
Qualified Hose Fittings
OTC, 1A, -40,-48 Crimps, Reusable Nipple Clamps
Reinforcement Material
Helical Wire and Textile
Supplier Part Number
2661-24-06000
Tube Material
Elastomer
Product Weight
56.50 lbs

Related Documents

Product Questions & Answers (1)

Question by: Larry E on Jun 11, 2025, 3:45 PM
Is this hose okay for gasoline transfer, or am I gonna have problems?
Answer by: Customer Support on Jun 12, 2025, 8:12 PM
This hose is indeed suitable for gasoline transfer, along with hydraulic circuits, lubrication oil systems, air, water, and certain chemical transfers. It's built with a conductive construction, which adds a safety margin when handling fuel and chemical media.
