Wire InsertED Suction HSE

Description & Features

Designed for suction-line service across a range of media, including hydraulic and lubrication oils, gasoline, air, water, and chemical transfer, this Dash -48 hose from Eaton Aeroquip is built to perform reliably under demanding industrial conditions. The blue elastomer cover is paired with a synthetic rubber tube and reinforced with helical wire and textile in a 2-ply braid construction, giving the hose both flexibility and structural integrity through a rated impulse cycle life of 500,000 cycles.

The Wire InsertED Suction Hose carries SAE 100R4 certification and meets ABS, USCG, Bureau Veritas, and MSHA compliance standards, making it well suited for marine and mining environments. A minimum bend radius of 18 inches and a minimum working temperature of -40°F support broad application versatility. Compatible fittings include OTC, TTC, -40 and -48 crimps, and reusable nipple clamps. The lay line is embossed, and the hose is conductive by design.

SKU: 2661-48

Supplier Part Number (MPN): 2661-48

Specifications

Abrasion Resistance Standard	Cover Material Chlorinated Polyethylene	Dash Size 48	For Use With TTC/Z, OTC, -40,-48 Crimps, Reusable Nipple Clamps Series Hose Fittings	Hose Color Blue	Hose Type Conductive	Impulse Cycle 500000	Impulse Cycle Life 500000	Inside Diameter 3 in	Lay Line Style Ink Transfer	Nominal Size #03	Package Form Bulk	Reinforcement 2-Ply Braided Brass-Plated Steel Wire	Resistance Abrasion	Resistance Properties Abrasion	Series 2661 Series	Tube Material Chlorinated Polyethylene

Product Questions & Answers (3)

Question by: Denise P on Jun 29, 2025, 4:59 PM

Is this hose okay for suction on hydraulic oil lines?

Answer by: Customer Support on Jul 1, 2025, 6:53 AM

It is indeed; this Aeroquip hose is designed specifically for suction applications involving hydraulic and lubrication oils.

Question by: Brett A on Jul 19, 2025, 9:30 PM

got a suction line job for hydraulic oil and a little gasoline, is this hose meant for that kind of mix?

Answer by: Customer Support on Jul 21, 2025, 8:54 AM

For suction service, the 2661 Series is intended for hydraulic and lubrication oils, gasoline, air, water, and chemical transfer, so those fluids fall within its stated application.

Question by: Cody G on May 7, 2025, 11:27 AM

does this hose handle suction on hydraulic systems or is it strictly a pressure line?

Answer by: Customer Support on May 9, 2025, 6:16 AM

Suction is exactly what it's built for. The helical wire reinforcement keeps the hose from collapsing under vacuum conditions, which is the main failure point on suction lines that aren't rated for it. Hydraulic and lubrication oil applications are both covered, and the synthetic rubber tube holds up to the fluid contact. SAE 100R4 certified, so it meets the standard spec most hydraulic suction setups call for.
