Aeroquip Hose And Coil - Code

Description & Features

This Aeroquip Hose And Coil is constructed with a 2-ply braid and elastomer cover, ensuring abrasion resistance and maximum durability in harsh operating conditions. Its robust construction can withstand high pressures, extending hose assembly life.

This blue, conductive hose is MSHA Approved, Bureau Veritas, and USCG compliant and certified to SAE 100R4 and ABS standards. It is suitable for suction applications involving hydraulic and lubrication oils, gasoline, air, water, and chemical transfer. It features a helical wire and textile reinforcement.

SKU: 2661-64

Supplier Part Number (MPN): 2661-64

Specifications

Abrasion Resistance 29	Alternate Part Numbers Alternate Part Number MINO-00015F51249	Application Suction application for hydraulic, lubrication oils, gasoline, air, water and chemical transfer.	Certifications SAE 100R4\|ABS	Color Blue	Compliances MSHA Approved\|Bureau Veritas\|USCG	Conductivity 30	Construction 2-ply braid	Cover Material Elastomer	Dash Size -64	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Maximum durability under harsh operating conditions\|Robust construction able to withstand highest pressures\|System engineered to extend hose assembly life	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Embossed	Minimum Bend Radius 24	Minimum Bend Radius 24	Minimum Working Temperature -40	Product Width 4.69	Qualified Hose Fittings OTC, TTC, -40,-48 Crimps, Reusable Nipple Clamps	Reinforcement Material Helical Wire and Textile	Sub Brand Aeroquip	Supplier Part Number 2661-64	Tube Material Synthetic Rubber	Product Weight 9.58 lbs

Product Questions & Answers (1)

Question by: Vince W on Mar 11, 2026, 6:50 AM

What kind of stuff can this hose handle? I'm using it for a hydraulic system.

Answer by: Customer Support on Mar 12, 2026, 9:54 PM

Designed for suction applications, this hose is suitable for hydraulic and lubrication oils, gasoline, air, water, and even some chemical transfers.
