16FP-16MJ BULKHEAD STRAIGHT

Description & Features

This straight bulkhead fitting features a female NPTF thread on one end and a male JIC 37-degree flare on the other. This 16FP-16MJ BULKHEAD STRAIGHT fitting is constructed from steel for durability and reliability.

The female NPTF thread (B1) measures 1-11/2 inches per SAE J476 specifications, with a drill size of 0.938 mm. The male JIC 37-degree flare thread (B2) measures 1-5/16-12 inches per SAE J514, with a drill size of 0.844 mm. The overall length of the straight steel fitting is 3.230 mm.

SKU: 2705-16-16

Supplier Part Number (MPN): 2705-16-16

Alternate Part Numbers: C1EF59

Specifications

Connection Size 1 1 in	Connection Size 2 1 in	Connection Type FNPT, Male JIC	Connection Type 1 Male SAE 37 deg JIC Flare	Connection Type 2 Female SAE NPTF	Dimension Standards SAE J476, SAE J514	Dimensions 3.24 in L	Finish Trivalent Zinc-Plated	Fitting Type Adapter	Hex Size 1-5/8	Material Steel	Material Construction AISI 12L14/1045 Steel	Maximum Operating Pressure 3000 psi	Series 2705 Series	Thread 2 Drill Dimensions 0.844 in	Thread B1 Drill Dimensions 0.938 in	Thread B2 Drill Dimensions 0.844 in	Thread Size 1-5/16-12 x 1-11-1/2 x 1-5/16-12

Product Questions & Answers (1)

Question by: Curt P on Dec 9, 2025, 11:29 AM

Will this bulkhead fitting hold up to hydraulic pressures without leaking?

Answer by: Customer Support on Dec 10, 2025, 5:17 PM

Constructed from steel, this straight bulkhead fitting is designed for durability and reliability in hydraulic applications.
