Hose

Description & Features

This Eaton Aeroquip hose is constructed with a Teflon tube and aramid polyester cover, reinforced with stainless steel. The blue -6 dash size hose is ideal for steam, compressor discharge, and chemical applications, and is compliant with USCG and DNV standards. Note that it is not recommended for steam-cold water cycling.

The hose withstands vibration and impulsing and is impervious to degradation over a wide temperature range. It has a minimum bend radius of 4 and a minimum working temperature of -100.

SKU: 2807-6

Supplier Part Number (MPN): 2807-6

Alternate Part Numbers: C1BJ86, MI-00332510, MINO-00015F72492

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number C1BJ86, Alternate Part Number MI-00332510, Alternate Part Number MINO-00015F72492, Alternate Part Number MINO-00925X09924	Application Ideal for steam, compressor discharge and virtually all chemical applications. Not recommended for steam-cold water cycling.	Certifications ABS\|SAE 100R14A	Color Blue	Compliances USCG\|DNV	Conductivity 30	Construction 1 Ply Braid	Cover Material Aramid Polyester	Dash Size -6	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Withstands vibration and impulsing\|Impervious to degradation\|Wide temperature range	ICC Hoses and Flexible Tubes	Language English	Minimum Bend Radius 4	Minimum Working Temperature -100	Product Width 0.46	Reinforcement Material Stainless Steel	Sub Brand Aeroquip	Supplier Part Number 2807-6	Tube Material Teflon	Product Weight 0.97 lbs

Product Questions & Answers (3)

Question by: Steve O on Dec 7, 2025, 8:09 AM

got a tight spot to route it, how sharp can i bend this -6 teflon hose without kinking it

Answer by: Customer Support on Dec 9, 2025, 6:38 AM

For routing, the minimum bend radius is 4 inches. Keeping your bend at or above that radius is the safe target for a -6 hose like this, especially in a cramped install.

Question by: Rick K on Dec 6, 2025, 6:26 AM

does this hose hold up to chemical exposure or is it gonna break down over time?

Answer by: Customer Support on Dec 8, 2025, 6:05 AM

Teflon tubing handles virtually all chemical applications without degrading. The PTFE construction is naturally impervious to chemical breakdown, so it holds up in harsh fluid environments where standard rubber hose would fail pretty quickly. Just keep in mind it is not recommended for steam-to-cold-water cycling applications.

Question by: Harold C on Apr 6, 2025, 8:21 AM

got a steam line that sees a lot of shake and pressure spikes. is this 2807-6 hose built for that kind of abuse?

Answer by: Customer Support on Apr 7, 2025, 11:06 AM

Built for rough service, the 2807 Series PTFE hose is called out for withstanding vibration and impulsing, with a stainless steel braid reinforcement and a premium abrasion-resistant cover.
