2BVM Series Steel Barstock Body Ball Valve, 1/2 NPT Ports, 0.55 Inch Orifice, 15.0000 CV Rating

Description & Features

Designed for industrial applications this ball valve is engineered from durable carbon steel with a black phosphate coating for enhanced corrosion resistance. It features a 0.55-inch orifice and 1/2 NPT ports ensuring robust performance with a 15.0000 CV rating.

This valve supports a pressure rating of 2000 PSI for sizes from 1/4" to 1" making it suitable for high-pressure fluid control. The ball and stem are made of nickel-chrome plated carbon steel for superior longevity and reliability.

Constructed with reinforced Teflon (PTFE) seals and ball seats it provides excellent chemical resistance and durability under various operating conditions. The handle is zinc-plated and equipped with a vinyl grip for easy operation.

Manufactured by Stauff-Special Quotes this 2BVM Series Steel Barstock Body Ball Valve 1/2 NPT Ports 0.55 Inch Orifice 15.0000 CV Rating is ideal for managing fluid flow in demanding environments.

Supplier Part Number: 6100092170

MPN: 6100092170

Specifications

CV Factor 15.00	Brand Stauff-Special Quotes	Brand Stauff Corporation	Pack Size 1.00	UOM EA	Orifice Diameter 0.55	Ports 1/2 NPT	Ports 1/2 NPT	Supplier Part Number 6100092170	Alternate Part Numbers Alternate Part Number 2BVM2008S, Alternate Part Number BV4L-2-N08-P072-U, Alternate Part Number BV4L2N08P072U, Alternate Part Number BV9L-2-N08-P072-Y, Alternate Part Number C1KU55, Alternate Part Number STNA31046	Product Weight 0.80 lbs

Similar Products

Model Number	Ports	Orifice Diameter	CV Factor	Price	Action
6100092170 2BVM Series Steel Ball Valve	1/2 NPT	0.55	15.0000
STNA31048 2BVM Series Steel Ball Valve	3/4 NPT	0.67	23.0000

Product Questions & Answers (3)

Question by: Chad W on Oct 29, 2025, 5:15 PM

what's the pressure rating on this valve, and does it hold up at higher temps the same way?

Answer by: Customer Support on Oct 31, 2025, 6:39 AM

At standard cold, non-shock conditions, the 1/2 inch size falls in the 1/4 to 1 inch range, so you're looking at a 2000 PSI rating. That said, the pressure rating does drop off as temperature climbs. Running it at elevated temps means you'll see a reduced ceiling compared to that 2000 PSI figure, so it's worth factoring in your operating conditions before putting it to work in a hot environment.

Question by: Daryl S on Aug 18, 2025, 7:16 PM

What size ports does this valve have? Just wanna make sure it'll fit my setup before I order.

Answer by: Customer Support on Aug 20, 2025, 11:22 AM

This ball valve comes with 1/2 NPT ports, which should be compatible with standard 1/2 NPT connections.

Question by: Lance P on Jan 13, 2026, 9:39 AM

got a 1/2 npt hydraulic line, will this valve thread right in or is it some oddball port?

Answer by: Customer Support on Jan 14, 2026, 7:47 PM

Fit-wise it uses standard 1/2 NPT ports, so it threads into other 1/2 NPT connections.
