Designed for demanding industrial environments, the Danfoss / Eaton Socket is a stainless steel female half quick disconnect coupling from the Hansen 2HKIG/2HKIL series. It features a push-to-connect end with a 1/4" NPTF port and a ball lock internal connection mechanism, allowing fast, tool-free coupling and decoupling in the field.
With a rated flow of 2.2 gallons per minute and a minimum working temperature of -40°F, this coupling is suited for chemical processing, food and beverage, military, and aerospace applications. Buna-N seals provide reliable fluid compatibility across a range of media, and the stainless steel construction supports use in corrosive or sanitary service conditions. Performance exceeds ISO 16028 operating pressure requirements.
SKU: 2HIG16
Supplier Part Number (MPN): 2HIG16
|
Alternate Part Numbers
MINO-00015X05199
|
Application
Chemical, Food and Beverage, Military, Aerospace
|
Brand
Danfoss Power Solutions (II LLC Aeroquip)
|
Brand
Aeroquip
|
Pack Size
1.00
|
UOM
EA
|
End Gender 1
13553
|
End Gender 2
13555
|
End Size 2
0.25
|
End Type 1
Push to Connect
|
End Type 2
NPTF
|
Features
Quick connect and disconnect|No need for special tools|Exceeds ISO 16028 operating pressures
|
Flow Rate1
2.2 gallons per minute
|
ICC
Quick Disconnect Couplings
|
Internal Connection Type
Ball Lock
|
Item Type
Female Half
|
Language
English
|
Minimum Working Temperature
-40
|
Net Pack Quantity Units
EA
|
Product Material
Stainless Steel
|
Product Width
1.06
|
Safety locking Mechanism
None
|
Seal Material
Buna-N
|
Sub Brand
Hansen
|
Supplier Part Number
2HIG16
|
Product Weight
0.23 lbs
|
