Aeroquip M/M 2W Reusable Fitting

Ask A Question

Description & Features

Constructed from carbon steel, this male-to-male reusable hose fitting connects a SAE 37 (JIC 45°) flare end to a hose end in a two-way configuration, with a -16 hose dash size and a 1.75-inch hex. The 1.0700 drop dimension makes it well-suited for installations where precise routing clearance matters.

The Aeroquip M/M 2W Reusable Fitting is part of the Aeroquip 2R Series, designed for reuse across a wide range of hydraulic hose assemblies. Reusable construction helps reduce assembly time and supports efficient production workflows without sacrificing durability. The JIC 45° flare connection type is a widely recognized standard in hydraulic line assembly, supporting reliable, leak-resistant joints.

SKU: 2RA16FJA16

Supplier Part Number (MPN): 2RA16FJA16

Specifications

a Dimensions
5.03 in
Compatible Hose ID
1 in
Connection Size 1
1 in
Connection Size 2
1 in
Connection Type
Female JIC Swivel, Hose
Connection Type 1
Hose
Connection Type 2
Female SAE 37 deg JIC Swivel
Construction Style
Reusable
Cut-Off Factor
3.05 in
Drop Dimensions
1 in
End Connection Torque
108 to 113 lb-ft
End Gender 1
Female
End Size 1
16
Finish
Zinc-Plated
Fitting Type
45 deg Elbow
For Use With
H280 Series Hoses
Hex Size
1-1/2 x 1-3/4 in
Hose Dash Size
16
Inside Diameter
0.76 in
Material
Steel
Material Construction
Carbon Steel
Segment Code
C
Series
2R Series
Thread Sealant
Without Thread Sealant
Thread Size
1-5/16-12
Thread Type
UN

Product Questions & Answers (1)

Sign In Hover me Please sign in to submit a question
Question by: Jimmy R on Feb 21, 2026, 1:32 PM
Wondering if this fitting will work with a standard hydraulic hose I got from the local shop?
Answer by: Customer Support on Feb 23, 2026, 7:13 AM
This Aeroquip fitting is designed for use with hoses adhering to the SAE 37 (JIC 45°) flare standard, ensuring a reliable, leak-resistant connection commonly found in hydraulic systems.
