Hose Barb-Metric Banjo Low Psi

Description & Features

This 90° elbow is a hose barb to metric adapter. The Adaptall fitting is constructed from steel and features a 1/2" hose barb connection on one side, and a M14 x 1.5 metric connection on the other. The total length of this hose barb-metric banjo low psi is 38mm, with a 14mm Adaptall A Misc, 14mm Adaptall B Misc, and 24mm Adaptall S Misc.

SKU: 3069HB-08-14

Supplier Part Number (MPN): 3069HB-08-14

Specifications

Connection Size 1 1/2 in	Connection Size 2 14 mm	Connection Type Barbed, Male Metric	Connection Type 1 Hose Barbed	Connection Type 2 Male Metric Banjo	Dimension Standards DIN 7631, ISO 12151, ISO 6149, ISO 9974	Dimensions 14 mm H	Finish Zinc-Plated	Fitting Type 90 deg Elbow	Material Steel	Material Construction Carbon Steel	s Misc Dimensions 24 mm	Series 3069HB Series	Thread Size M14x1.5

Product Questions & Answers (1)

Question by: Gene E on Dec 1, 2025, 6:18 PM

Got a metric banjo port on a pump I'm trying to plumb into some 1/2" hose, this 90 degree fitting gonna bridge that gap?

Answer by: Customer Support on Dec 3, 2025, 6:52 AM

That's exactly what this fitting is built for. One end is a standard 1/2" hose barb, the other is an M14 x 1.5 male metric thread, and the 90 degree elbow shape lets you route the hose at a right angle off the banjo port. Total length runs 38mm, so it's fairly compact. Steel construction throughout. As long as your port matches M14 x 1.5 and your hose ID is 1/2", you've got a direct fit.
