main product photo

Danfoss / Eaton 3270 Eclipse Air Brake Tubing

Ask A Question

Description & Features

Designed for truck and trailer air brake systems, this dash -6 red polyamide tubing meets SAE J844, SAE J1131, and SAE J2494-2 standards, with full DOT FMVSS 106 compliance. The Danfoss / Eaton 3270 Eclipse Air Brake Tubing is built around a multi-braid synthetic fiber reinforcement with a polyester cover, offering non-conductive performance and a rated impulse cycle life of 125,000 cycles.

A minimum bend radius of 1.5 inches and a low-temperature rating of -40°F make it well suited for formed tube assemblies and straight or pre-formed air brake harness configurations. Compatible with Qcab and push-to-connect fittings, it is appropriate for auxiliary air system routing alongside primary brake circuit applications. The proprietary blended nylon tube material contributes to flexibility without adding unnecessary weight.

SKU: 3270-06124

Supplier Part Number (MPN): 3270-06124

Alternate Part Numbers: MI-08207222, MINO-00803X00503

Specifications

Abrasion Resistance
28
Alternate Part Numbers
Alternate Part Number MI-08207222, Alternate Part Number MINO-00015X05576, Alternate Part Number MINO-00803X00503
Application
Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies
Certifications
SAE J844|SAE J1131|SAE J2494-2
Color
Red
Compliances
DOT FMVSS 106
Conductivity
13552
Construction
Multi Braid
Cover Material
Polyester
Dash Size
-6
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
12.00
UOM
FT
Features
Light weight to improve hose flexibility|Maximum durability under harsh operating conditions|High quality proprietary blended nylon materials
ICC
Hoses and Flexible Tubes
Impulse Cycle Life
125000 cycle
Language
English
Minimum Bend Radius
1.50
Minimum Bend Radius
1.5
Minimum Working Temperature
-40
Net Pack Quantity Units
FT
NMFC
70
Product Width
0.38
Qualified Hose Fittings
QCAB, Push to Connect
Reinforcement Material
Synthetic fiber
Sub Brand
Synflex
Supplier Part Number
3270-06124
Tube Material
Polyamide
Product Weight
0.08 lbs

Related Documents

Product Questions & Answers (2)

Question by: Gene W on Dec 9, 2025, 7:43 AM
does this tubing hold up when it gets real cold out? asking cause we run equipment through some pretty rough winters and need something that aint gonna get stiff and crack on us
Answer by: Customer Support on Dec 10, 2025, 9:44 AM
Cold weather performance is built into this tubing. The minimum working temperature is rated at -40 degrees, so it stays flexible and functional even in severe winter conditions without cracking or hardening. The polyamide tube material and polyester cover handle that kind of cold without breaking down.
Question by: Darryl W on Dec 17, 2025, 9:17 AM
got a -6 air brake line already, is this 3270 tubing the right size for that
Answer by: Customer Support on Dec 18, 2025, 10:53 AM
For sizing, the dash size on this product is -6. It is part of the Synflex Eclipse 3270 Series air brake hose and tubing line used on truck and trailer air brake systems and auxiliary air systems.
