main product photo

AEROQUIP AIRBRAKE TUBING 3/8 OD 3000FT(6

Ask A Question

Description & Features

This Aeroquip airbrake tubing is designed for use in truck and trailer air brake systems, as well as auxiliary air systems and air brake harness assemblies. Constructed with a multi-braid reinforcement and a polyamide tube material, the tubing offers light weight and flexibility with maximum durability.

This yellow airbrake tubing features a polyester cover material and provides premium abrasion resistance. It meets SAE J1131, SAE J2494-2, SAE J844, and DOT FMVSS 106 certifications and compliances. This non-conductive hose is compatible with QCAB and push-to-connect fittings, offering an impulse cycle life of 125,000 cycles and a minimum bend radius of 1.5 inches. It withstands minimum working temperatures of -40 degrees.

SKU: 3270-06144

Supplier Part Number (MPN): 3270-06144

Specifications

Abrasion Resistance
28
Alternate Part Numbers
Alternate Part Number MINO-00803X01096
Application
Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies
Certifications
SAE J1131|SAE J2494-2|SAE J844
Color
Yellow
Compliances
DOT FMVSS 106
Conductivity
13552
Construction
Multi Braid
Cover Material
Polyester
Dash Size
-6
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
12.00
UOM
FT
Features
Light weight to improve hose flexibility|Maximum durability under harsh operating conditions|High quality proprietary blended nylon materials
ICC
Hoses and Flexible Tubes
Impulse Cycle Life
125000 cycle
Language
English
Minimum Bend Radius
1.50
Minimum Bend Radius
1.5
Minimum Working Temperature
-40
Net Pack Quantity Units
FT
NMFC
70
Product Width
0.38
Qualified Hose Fittings
QCAB, Push to Connect
Reinforcement Material
Synthetic fiber
Sub Brand
Synflex
Supplier Part Number
3270-06144
Tube Material
Polyamide
Product Weight
0.08 lbs

Related Documents

Product Questions & Answers (1)

Question by: Danny M on Aug 31, 2025, 1:53 PM
What size fittings do I need for this tubing?
Answer by: Customer Support on Sep 1, 2025, 7:15 PM
This airbrake tubing works with QCAB and push-to-connect fittings.
