AEROQUIP AIRBRAKE 1/2 RED 100

Description & Features

Designed for truck and trailer air brake systems, this 1/2-inch Eaton Aeroquip Airbrake Hose, part of the Synflex Eclipse 3270 Series, is constructed with a nylon tube, synthetic fiber multi-braid reinforcement, and a red polyester cover rated for premium abrasion resistance. The non-conductive construction suits harsh operating environments where durability and flexibility are both priorities.

The AEROQUIP AIRBRAKE 1/2 RED 100 meets SAE J2494-2, SAE J844, and SAE J1131 certifications, and complies with DOT FMVSS 106, making it well-suited for use in regulated commercial vehicle brake harness assemblies, including both formed tube and straight configurations. A minimum bend radius of 2 inches and a rated impulse cycle life of 125,000 cycles reflect its suitability for demanding, repetitive-flex applications. The hose is also rated for a minimum working temperature of -40°F, supporting year-round use in cold-weather environments. Auxiliary air systems on commercial vehicles represent an additional application area beyond primary brake circuits.

SKU: 3270-0812-0100

Supplier Part Number (MPN): 3270-0812-0100

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00803X01138	Application Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies.	Certifications SAE J2494-2\|SAE J844\|SAE J1131	Color Red	Compliances DOT FMVSS 106	Conductivity 13552	Construction Multi Braid	Cover Material Polyester	Dash Size -8	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM FT	Features Light weight to improve hose flexibility\|Maximum durability under harsh operating conditions\|High quality proprietary blended nylon materials	ICC Hoses and Flexible Tubes	Impulse Cycle Life 125000 cycle	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 2	Minimum Bend Radius 2	Minimum Working Temperature -40	Net Pack Quantity Units FT	NMFC 70	Product Width 0.50	Reinforcement Material Synthetic fiber	Sub Brand Synflex	Supplier Part Number 3270-0812-0100	Tube Material Nylon	Product Weight 0.12 lbs

Product Questions & Answers (2)

Question by: Kirk B on Nov 25, 2025, 8:11 PM

Will this Aeroquip airbrake hose work okay for trailer air brake lines?

Answer by: Customer Support on Nov 27, 2025, 6:27 AM

Absolutely. The Aeroquip 3270 series hose is designed for truck and trailer air brake systems, along with auxiliary air systems.

Question by: Cody B on Jul 26, 2025, 1:03 PM

putting together an air brake harness, would this 1/2 inch red Aeroquip hose work for truck or trailer air systems?

Answer by: Customer Support on Jul 28, 2025, 6:19 AM

For air brake work, it fits the common use cases. It is listed for truck air brake systems, trailer air brake systems, and auxiliary air systems, including formed tubes and both formed and straight air brake harness assemblies.
