Aeroquip AIRBrake ORANGE 1/2 OD ECLIPSE

Description & Features

Designed for durability and flexibility, the Aeroquip AIRBrake ORANGE 1/2 OD ECLIPSE is an essential component for truck and trailer air brake systems. Constructed with high-quality proprietary blended nylon, this airbrake hose features a multi-braid design reinforced by synthetic fiber, providing premium abrasion resistance and a minimum bend radius of only 2 inches. The orange polyester cover ensures easy visibility and differentiation in complex systems.

Meeting stringent standards such as SAE J2494-2, SAE J844, and SAE J1131, this non-conductive hose is compliant with DOT FMVSS 106, ensuring reliable performance in auxiliary air systems and various air brake harness assemblies. It is compatible with QCAB and Push to Connect fittings, making it a versatile choice for industrial applications requiring robust and lightweight solutions.

SKU: 3270-0813-0100

Supplier Part Number (MPN): 3270-0813-0100

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00803X01146	Application Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies.	Certifications SAE J2494-2\|SAE J844\|SAE J1131	Color Orange	Compliances DOT FMVSS 106	Conductivity 13552	Construction Multi Braid	Cover Material Polyester	Dash Size -8	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM FT	Features Light weight to improve hose flexibility\|Maximum durability under harsh operating conditions\|High quality proprietary blended nylon materials	ICC Hoses and Flexible Tubes	Impulse Cycle Life 125000 cycle	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 2	Minimum Bend Radius 2	Minimum Working Temperature -40	Product Width 0.50	Qualified Hose Fittings QCAB, Push to Connect	Reinforcement Material Synthetic fiber	Sub Brand Synflex	Supplier Part Number 3270-0813-0100	Tube Material Nylon	Product Weight 0.12 lbs

Product Questions & Answers (1)

Question by: Rick S on Sep 8, 2025, 8:32 AM

What size fittings work with this air brake hose?

Answer by: Customer Support on Sep 10, 2025, 8:22 AM

This Aeroquip AIRBrake hose is compatible with QCAB and Push to Connect fittings.
