Danfoss / Eaton 3270 Eclipse Air Brake Tubing

Description & Features

Designed for truck and trailer air brake systems, this blue, 1/2-inch polyamide tube is built to perform reliably across a wide temperature range, down to -40°F. The Danfoss / Eaton 3270 Eclipse Air Brake Tubing features a multi-braid synthetic fiber reinforcement with a polyester cover that provides premium abrasion resistance under demanding road and fleet conditions.

Rated for 125,000 impulse cycles and compatible with push-to-connect and QCAB fittings, this tubing suits formed tube assemblies as well as straight and formed air brake harness configurations. Non-conductive construction and lightweight flexibility make it well suited for auxiliary air system routing alongside primary brake circuits. Certifications include SAE J1131, SAE J2494-2, and SAE J844, with compliance to DOT FMVSS 106.

SKU: 3270-08164

Supplier Part Number (MPN): 3270-08164

Specifications

Brand
Synflex® by Danfoss
Color
Blue
Conductive
Non-Conductive
Cover Material
Polyester
Dash Size
08
Impulse Cycle Life
125000
Inside Diameter
0.38 in
Material
Polymer
Material Construction
Polyamide
nmfc
70
Nominal Size
1/2 in
Reinforcement
Multi-Braided Synthetic Fiber
Resistance
Abrasion
Resistance Properties
Abrasion
Series
3270 Series
Tube Material
Polyamide

Similar Products

Model Number Nominal Size Length Wall Thickness Price Action
Nylon Air Brake Tubing, Green, 0.38 Inch OD, 0.06 Inch Wall Thickness, 500 Feet Per Pack

3270-0615-0500 Eclipse / Solstice Air Brake Tubing

3/8 in

Nylon Air Brake Tubing, Green, 0.50 Inch OD, 0.06 Inch Wall Thickness, 500 Feet Per Pack

3270-0815-0500 Eclipse / Solstice Air Brake Tubing

1/2 in

Nylon Air Brake Tubing, Red, 0.50 Inch OD, 0.06 Inch Wall Thickness, 1500 Feet Per Pack

3270-08124 Eclipse / Solstice Air Brake Tubing

1/2 in

Nylon Air Brake Tubing, Orange, 0.38 Inch OD, 0.06 Inch Wall Thickness, 500 Feet Per Pack

3270-0613-0500 Eclipse / Solstice Air Brake Tubing

3/8 in

Nylon Air Brake Tubing, Black, 0.50 Inch OD, 0.06 Inch Wall Thickness, 1500 Feet Per Pack

3270-08104 Eclipse / Solstice Air Brake Tubing

#08

Nylon Air Brake Tubing, Red, 0.63 Inch OD, 0.09 Inch Wall Thickness, 250 Feet Per Pack

3270-1012-0250 Eclipse / Solstice Air Brake Tubing

0.094 in

Nylon Air Brake Tubing, Blue, 0.38 Inch OD, 0.06 Inch Wall Thickness, 500 Feet Per Pack

3270-0616-0500 Eclipse / Solstice Air Brake Tubing

3/8 in

Nylon Air Brake Tubing, Orange, 0.63 Inch OD, 0.09 Inch Wall Thickness, 250 Feet Per Pack

3270-1013-0250 Eclipse / Solstice Air Brake Tubing

0.094 in

Nylon Air Brake Tubing, Black, 0.75 Inch OD, 0.09 Inch Wall Thickness, 250 Feet Per Pack

3270-1210-0250 Eclipse / Solstice Air Brake Tubing

3/4 in

0.094 in

Nylon Air Brake Tubing, Black, 0.63 Inch OD, 0.09 Inch Wall Thickness, 750 Feet Per Pack

3270-10103 Eclipse / Solstice Air Brake Tubing

0.094 in

Nylon Air Brake Tubing, Black, 0.13 Inch OD, 0.02 Inch Wall Thickness, 1000 Feet Per Pack

4245-0220-1000 Eclipse / Solstice Air Brake Tubing

Nylon Air Brake Tubing, Red, 0.38 Inch OD, 0.06 Inch Wall Thickness, 500 Feet Per Pack

3270-0612-0500 Eclipse / Solstice Air Brake Tubing

3/8 in

Nylon Air Brake Tubing, Blue, 0.25 Inch OD, 0.04 Inch Wall Thickness, 1000 Feet Per Pack

4247-0416-1000 Eclipse / Solstice Air Brake Tubing

1/4 in

Nylon Air Brake Tubing, Black, 0.25 Inch OD, 0.04 Inch Wall Thickness, 1000 Feet Per Pack

4247-0410-1000 Eclipse / Solstice Air Brake Tubing

1/4 in

Nylon Air Brake Tubing, Yellow, 0.38 Inch OD, 0.06 Inch Wall Thickness, 500 Feet Per Pack

3270-0614-0500 Eclipse / Solstice Air Brake Tubing

3/8 in

Nylon Air Brake Tubing, Green, 0.25 Inch OD, 0.04 Inch Wall Thickness, 1000 Feet Per Pack

4247-0415-1000 Eclipse / Solstice Air Brake Tubing

1/4 in

Nylon Air Brake Tubing, Orange, 0.25 Inch OD, 0.04 Inch Wall Thickness, 1000 Feet Per Pack

4247-0413-1000 Eclipse / Solstice Air Brake Tubing

1/4 in

Nylon Air Brake Tubing, Black, 0.31 Inch OD, 0.04 Inch Wall Thickness, 500 Feet Per Pack

4245-0520-0500 Eclipse / Solstice Air Brake Tubing

5/16 in

Nylon Air Brake Tubing, Blue, 0.63 Inch OD, 0.09 Inch Wall Thickness, 250 Feet Per Pack

3270-1016-0250 Eclipse / Solstice Air Brake Tubing

0.094 in

Nylon Air Brake Tubing, Yellow, 0.25 Inch OD, 0.04 Inch Wall Thickness, 1000 Feet Per Pack

4247-0414-1000 Eclipse / Solstice Air Brake Tubing

1/4 in

Nylon Air Brake Tubing, Red, 0.50 Inch OD, 0.06 Inch Wall Thickness, 500 Feet Per Pack

3270-0812-0500 Eclipse / Solstice Air Brake Tubing

1/2 in

Nylon Air Brake Tubing, Black, 0.50 Inch OD, 0.06 Inch Wall Thickness, 500 Feet Per Pack

3270-0810-0500 Eclipse / Solstice Air Brake Tubing

1/2 in

Nylon Air Brake Tubing, Black, 0.50 Inch OD, 0.06 Inch Wall Thickness, 100 Feet Per Pack

3270-0810-0100 Eclipse / Solstice Air Brake Tubing

1/2 in

Nylon Air Brake Tubing, Black, 0.38 Inch OD, 0.06 Inch Wall Thickness, 500 Feet Per Pack

3270-0610-0500 Eclipse / Solstice Air Brake Tubing

3/8 in

Nylon Air Brake Tubing, Black, 0.63 Inch OD, 0.09 Inch Wall Thickness, 250 Feet Per Pack

3270-1010-0250 Eclipse / Solstice Air Brake Tubing

0.094 in

Nylon Air Brake Tubing, Green, 0.75 Inch OD, 0.09 Inch Wall Thickness, 250 Feet Per Pack

3270-1215-0250 Eclipse / Solstice Air Brake Tubing

3/4 in

0.094 in

Nylon Air Brake Tubing, Black, 0.25 Inch OD, 0.04 Inch Wall Thickness, 100 Feet Per Pack

4247-0410-0100 Eclipse / Solstice Air Brake Tubing

1/4 in

Nylon Air Brake Tubing, Red, 0.25 Inch OD, 0.04 Inch Wall Thickness, 1000 Feet Per Pack

4247-0412-1000 Eclipse / Solstice Air Brake Tubing

1/4 in

Nylon Air Brake Tubing, Green, 0.63 Inch OD, 0.09 Inch Wall Thickness, 250 Feet Per Pack

3270-1015-0250 Eclipse / Solstice Air Brake Tubing

0.094 in

Nylon Air Brake Tubing, Black, 0.38 Inch OD, 0.06 Inch Wall Thickness, 100 Feet Per Pack

3270-0610-0100 Eclipse / Solstice Air Brake Tubing

3/8 in

AEROQUIP AIRBRAKE 3/8 BLK 1000

3270-0610-1000

3/8 in

Danfoss / Eaton 3270 Eclipse Air Brake Tubing

3270-06104

3/8 in

AEROQUIP AIRBRAKE TUBING ECLIPSE 3/8 OD RED 100

3270-0612-0100

3/8 in

Danfoss / Eaton 3270 Eclipse Air Brake Tubing

3270-06124

3/8 in

AEROQUIP AirBrake Tubing Orange 3/8OD Eclipse

3270-0613-0100

3/8 in

DANFOSS / EATON AIRBRAKE TUBING 3/8 OD OR

3270-06134

#06

Air Brake Tubing

3270-0614-0100

3/8 in

AEROQUIP AIRBRAKE TUBING 3/8 OD 3000FT(6

3270-06144

3/8 in

Air Brake Tubing

3270-0615-0100

3/8 in

Danfoss / Eaton 3270 Eclipse Air Brake Tubing

3270-06154

3/8 in

Aeroquip AIRBrake Tubing ECLIPSE 3/8 OD

3270-0616-0100

3/8 in

AEROQUIP ECLIPSE SAE J844D TYPE 3B BLUE 3/8 AIRBRAKE TUBIN

3270-06164

3/8 in

Aeroquip ECLIPSE 1/2 BLK 1000FT

3270-0810-1000

1/2 in

AEROQUIP AIRBRAKE 1/2 RED 100

3270-0812-0100

1/2 in

Aeroquip AIRBrake ORANGE 1/2 OD ECLIPSE

3270-0813-0100

1/2 in

AEROQUIP AIRBRAKE ORANGE 1/2 OD Eclipse 500 FT

3270-0813-0500

1/2 in

DANFOSS / EATON AIRBRAKE TUBING 1/2 OD OR

3270-08134

#08

Aeroquip AIRBrake Tubing YELLOW 1/2 OD

3270-0814-0500

1/2 in

DANFOSS / EATON AIRBRAKE TUBING 1/2 OD YE

3270-08144

#08

DANFOSS / EATON AIRBRAKE 1/2 GRN 100

3270-0815-0100

1/2 in

Danfoss / Eaton 3270 Eclipse Air Brake Tubing

3270-08154

#08

AEROQUIP AIRBRAKE 1/2 OD Eclipse 100 FT

3270-0816-0100

1/2 in

Air Brake Tubing

3270-0816-0500

1/2 in

AEROQUIP ECLIPSE 5/8 BLK 100

3270-1010-0100

0.094 in

Danfoss / Eaton AIRBrake Tubing RED 5/8OD

3270-1012-0100

0.094 in

DANFOSS / EATON AIRBRAKE 3/8 YLW 100

3270-1014-0100

0.094 in

Danfoss / Eaton AIRBrake Tubing YELLOW 5/8 OD ECLI

3270-1014-0250

0.094 in

Danfoss / Eaton AIRBrake Tubing

3270-1015-0100

0.094 in

DANFOSS / EATON AIRBRAKE BLUE 5/8

3270-1016-0100

0.094 in

AEROQUIP ECLIPSE 3/4 BLK -comes in 100 footers

3270-1210-0100

3/4 in

0.094 in

Danfoss / Eaton ORANGE AIRBrake Tubing

3270-1213-0100

3/4 in

0.094 in

DANFOSS / EATON AIRBRAKE TUBING ORANGE 3/4

3270-1213-0250

3/4 in

0.094 in

DANFOSS / EATON 5/8 RD 250FT

3270-10123

10

0.094 in

DANFOSS / EATON AIRBRAKE TUBING 5/8 OD YE

3270-10143

10

0.094 in

DANFOSS / EATON 5/8 GRN 250FT

3270-10153

10

0.094 in

DANFOSS / EATON 5/8 BLUE 250FT

3270-10163

10

0.094 in

Danfoss / Eaton 3270 Eclipse Air Brake Tubing

3270-12103

#12

0.094 in

DANFOSS / EATON AIRBRAKE TUBING 3/4 OD RE

3270-12123

#12

0.094 in

DANFOSS / EATON AIRBRAKE TUBING 3/4 OD OR

3270-12133

#12

0.094 in

DANFOSS / EATON AIRBRAKE TUBING 3/4 OD GR

3270-12153

3/4 in

0.094 in

DANFOSS / EATON AIRBRAKE TUBING 3/4 OD BL

3270-12163

#12

0.094 in

Product Questions & Answers (3)

Question by: Dustin K on Aug 23, 2025, 6:30 AM
Is this air brake tubing DOT compliant?
Answer by: Customer Support on Aug 24, 2025, 11:25 AM
Yes, this Synflex Eclipse tubing meets DOT FMVSS 106 standards.
Question by: Eddie B on Jul 2, 2025, 8:30 AM
got a truck with 1/2 inch air brake lines, is this the right stuff for that or am i off a size
Answer by: Customer Support on Jul 4, 2025, 6:30 AM
For truck and trailer air brake systems, this tubing is a 1/2 inch size (dash -8) and it meets SAE J1131, SAE J2494-2, and SAE J844, plus DOT FMVSS 106 compliance, so it fits the common requirements for air brake tubing in those applications.
Question by: Terry H on Jan 27, 2026, 8:10 PM
does this tubing hold up when it's routed close to the frame on a trailer rig, where it's gonna flex and rub a little on every bump?
Answer by: Customer Support on Jan 29, 2026, 6:55 AM
Premium abrasion resistance is built into the cover on this tubing, and the polyester outer layer handles that kind of repeated contact better than standard air brake hose. The multi-braid construction with synthetic fiber reinforcement also keeps the tube from kinking when it's bent tight around frame routing. Minimum bend radius is 2 inches, so as long as you've got that clearance at the routing points, it'll stay flexible without fatiguing the wall. The polyamide tube material holds its shape under pressure and doesn't get brittle in cold weather either, rated down to negative 40 degrees.
