DANFOSS / EATON 5/8 RD 250FT

Description & Features

Designed for truck and trailer air brake systems, this 5/8-inch red hose from the Synflex Eclipse 3270 Series by Danfoss / Eaton is built for demanding transport applications. The polyamide tube is reinforced with synthetic fiber multi-braid construction and covered in a polyester outer layer rated for premium abrasion resistance, a combination suited to the rigors of brake harness assemblies, both formed and straight.

The Danfoss / Eaton 5/8 Rd 250Ft carries certifications to SAE J1131, SAE J844, and SAE J2494-2, with full compliance to DOT FMVSS 106. Rated for a minimum bend radius of 2.5 inches and a working temperature floor of -40°F, it maintains flexibility across a wide range of service conditions. Compatible with QCAB and push-to-connect fittings, this hose is non-conductive and supports an impulse cycle life of 125,000 cycles. Suitable for auxiliary air systems in addition to primary brake circuit use, it is available in a 250-foot reel length.

SKU: 3270-10123

Supplier Part Number (MPN): 3270-10123

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00803X01186	Application Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies	Certifications SAE J1131\|SAE J844\|SAE J2494-2	Color Red	Compliances DOT FMVSS 106	Conductivity 13552	Construction Multi Braid	Cover Material Polyester	Dash Size -10	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Light weight to improve hose flexibility\|Maximum durability under harsh operating conditions\|High quality proprietary blended nylon materials	ICC Hoses and Flexible Tubes	Impulse Cycle Life 125000 cycle	Language English	Minimum Bend Radius 2.50	Minimum Bend Radius 2.5	Minimum Working Temperature -40	Net Pack Quantity Units FT	NMFC 70	Product Width 0.63	Qualified Hose Fittings QCAB, Push to Connect	Reinforcement Material Synthetic fiber	Sub Brand Synflex	Supplier Part Number 3270-10123	Tube Material Polyamide	Product Weight 0.18 lbs

Product Questions & Answers (1)

Question by: Hugh D on Nov 27, 2025, 9:24 PM

Can this hose handle the vibrations from a truck's air brake system without failing?

Answer by: Customer Support on Nov 29, 2025, 6:42 AM

Designed for truck and trailer air brake systems, the Synflex Eclipse 3270 series hose uses a synthetic fiber multi-braid construction for reinforcement, which helps it withstand vibration and impulse stresses. It's also rated for 125,000 impulse cycles.
