Danfoss / Eaton ORANGE AIRBrake Tubing

Description & Features

Designed for truck and trailer air brake systems as well as auxiliary air applications, the Danfoss / Eaton Orange Airbrake Tubing is a Dash -12 multi-braid hose built from high-quality proprietary blended nylon tube material with a polyester cover and synthetic fiber reinforcement. The orange color aids quick identification in harness assemblies, and the ink jet lay line supports traceability in the field.

Rated for a minimum working temperature of -40°F and a minimum bend radius of 3 inches, this tubing handles demanding thermal and routing conditions common in heavy-duty vehicle brake harness assemblies, both formed and straight configurations. An impulse cycle life of 125,000 cycles reflects the durability expected under continuous brake system use. The non-conductive construction and premium abrasion resistance add reliability in routed installations. Compliance with SAE J844, SAE J2494-2, SAE J1131, and DOT FMVSS 106 confirms suitability for regulated commercial vehicle brake applications. Part of the Synflex Eclipse 3270 Series from Eaton's Aeroquip brand family.

SKU: 3270-1213-0100

Supplier Part Number (MPN): 3270-1213-0100

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00803X01221	Application Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies.	Certifications SAE J844\|SAE J2494-2\|SAE J1131	Color Orange	Compliances DOT FMVSS 106	Conductivity 13552	Construction Multi Braid	Cover Material Polyester	Dash Size -12	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM FT	Features Light weight to improve hose flexibility\|Maximum durability under harsh operating conditions\|High quality proprietary blended nylon materials	ICC Hoses and Flexible Tubes	Impulse Cycle Life 125000 cycle	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 3	Minimum Working Temperature -40	Net Pack Quantity Units FT	NMFC 70	Product Width 0.75	Reinforcement Material Synthetic fiber	Sub Brand Synflex	Supplier Part Number 3270-1213-0100	Tube Material Nylon	Product Weight 8.60 lbs

Product Questions & Answers (1)

Question by: Harvey H on Feb 17, 2026, 6:53 PM

What kind of temperatures can this tubing handle?

Answer by: Customer Support on Feb 19, 2026, 12:16 PM

It's rated to handle temperatures down to -40°F, so it should hold up in some pretty cold conditions.
