Engineered for fuel and liquid transfer with light vacuum capability, this hose features a PVDF inner tube, polyester braid reinforcement, and a perforated PVC alloy cover that provides strong resistance to abrasion and elevated temperatures. The construction supports a minimum bend radius of 1.5 inches and a working temperature range starting at -40°F, making it well-suited for demanding engine compartment environments.
The 100 Feet of 35FH04 on a Retail Spool ships in a convenient spool format and is compatible with a range of qualified fittings, including Aeroquip 4738, 4739, 4740, 4741, 4742, 4743, and 4797 series ends. Rated to SAE J30R6 and SAE J1527B1 standards, this Synflex by Danfoss hose consolidates fuel line requirements across multiple applications into a single, reliable product. The non-conductive, ink jet lay line construction rounds out a design built for consistent performance in fuel system assemblies.
SKU: 35FH-40201-001
Supplier Part Number (MPN): 35FH-40201-001
|
Alternate Part Numbers
MINO-00015X05864
|
Application
Liquid and light vacuum.
|
Certifications
SAE J30R6|SAE J1527B1
|
Color
Black
|
Conductivity
13552
|
Construction
1 Ply Braid
|
Cover Material
PVC Alloy
|
Cover Style
Perforated
|
Dash Size
-4
|
Brand
Danfoss Power Solutions (II LLC Aeroquip)
|
Brand
Aeroquip
|
Pack Size
1.00
|
UOM
FT
|
Features
Highly abrasion resistant cover|Small number of hoses for many fuel options|Proven reliability with high temperature resistance
|
ICC
Hoses and Flexible Tubes
|
Language
English
|
Lay Line Style
Ink Jet
|
Minimum Bend Radius
1.50
|
Minimum Bend Radius
1.5
|
Minimum Working Temperature
-40
|
Net Pack Quantity Units
FT
|
NMFC
70
|
Product Width
0.49
|
Qualified Hose Fittings
4738, 4742, 4740, 4743, 4797, 4741, 4739
|
Reinforcement Material
Polyester
|
Sub Brand
Synflex
|
Supplier Part Number
35FH-40201-001
|
Tube Material
PVDF
|
Product Weight
0.12 lbs
|
