main product photo

35M Series Vane Motor, 115 Ring Size, 14 Tooth SAE C Splined Shaft, Outlet Port Connections In-line (C)

Ask A Question

Description & Features

This Eaton Vickers 35M Series Vane Motor is designed for reliable and efficient performance in demanding applications such as elevator scraper drives, hydrostatic drives, and auxiliary equipment.

The motor features a 115 ring size, a 14 Tooth SAE C splined shaft, and inline port connections. It offers a torque rating of 115 lb-in per 100 psi and utilizes Buna-N seals for compatibility with hydraulic fluids.

Featuring a 2-Bolt SAE C mounting flange and 1-1/2" SAE 4-Bolt flange ports, this vane motor is built to provide long-lasting and quiet operation. A 3/8 NPT drain port is included in the rear cover.

SKU: 312062-3

Supplier Part Number (MPN): 312062-3

Alternate Part Numbers: 35M115A11C20, C1BL63, F08020

Specifications

Color
Gray
Configuration
Single
Design Code
20
Dimensions
10.75 in L x 8.38 in W x 6.25 in H
Frame Size
35
Grp Specifications
2-Bolt SAE C Mounting Flange, 1-1/2 in SAE 4-Bolt Flange Port, 3/8 in NPT Drain Port (Rear Cover)
Housing Material
Iron
Mounting Type
4-Bolt Flanged
Rotation Direction
Right Hand
Seal Material
Buna-N
Segment Code
A
Series
35M Series
Shaft Seal
Single
Shaft Type
Splined

Product Questions & Answers (3)

Sign In Hover me Please sign in to submit a question
Question by: Donna H on Feb 17, 2026, 6:04 PM
Would this Eaton Vickers motor be alright for a elevator scraper drive?
Answer by: Customer Support on Feb 19, 2026, 3:47 PM
Given its listed applications, this 35M series vane motor can certainly handle elevator scraper drives.
Question by: Judy A on Apr 4, 2025, 3:15 PM
trying to swap out an old Eaton Vickers motor, is this one the 35M115A-11C20 model with the in-line ports?
Answer by: Customer Support on Apr 5, 2025, 6:03 PM
Match it up by the model number 35M115A-11C20 and the port location called out as in-line (C). It is also a single configuration 35M series vane motor with ring size 115, so those identifiers should line up with what you are replacing.
Question by: Brett K on Jul 1, 2025, 5:08 PM
Trying to match up a replacement for an old Vickers vane motor on an elevator scraper drive. The shaft on mine's got 14 teeth, SAE C spline, and the mounting flange is 2-bolt SAE C. This the right unit for that?
Answer by: Customer Support on Jul 3, 2025, 8:43 AM
For that configuration, yes, this one lines up. The 35M115A-11C20 runs a 14 tooth SAE C splined shaft and mounts on a 2-bolt SAE C flange, so the mechanical fit is there. Ports are 1-1/2 inch SAE 4-bolt flange, in-line configuration, with a 3/8 NPT drain in the rear cover. If your existing hydraulic connections matches that layout, you're in good shape for a direct swap.
