100R7 50 FT Box THERMOPLASTIC HOSE

Description & Features

Supplied in a 50-foot box, the Aeroquip 100R7 50 FT Box Thermoplastic Hose is built to SAE 100R7 standards and designed for use in medium-pressure hydraulic and fluid transfer applications. Thermoplastic construction gives this hose good flexibility and resistance to abrasion, oils, and weathering, making it well-suited for mobile equipment, agricultural machinery, and general industrial fluid lines.

The box format provides a convenient, manageable length for field fabrication or shop assembly, reducing waste and simplifying cut-to-length work. As an Aeroquip product, it meets the material and performance requirements expected of branded hydraulic hose in demanding service environments.

SKU: 3TR7-03-050BX

Supplier Part Number (MPN): 3TR7-03-050BX

Specifications

Brand
Synflex® by Danfoss
Abrasion Resistance
Standard
Cover Material
Polyurethane
Dash Size
03
Hose Color
Black
Hose Type
Conductive
Impulse Cycle
150000
Inside Diameter
3/16 in
Lay Line Style
Ink Transfer
Nominal Size
3/16 in
Package Form
Box
Reinforcement
1-Ply Braided Fabric
Resistance Properties
Abrasion, Chemical
Series
3TR7 Series
Tube Material
Polyamide

Product Questions & Answers (1)

Question by: Wes H on Dec 19, 2025, 12:15 PM
Just making sure, this is a 50-foot length of the 100R7 hose, right?
Answer by: Customer Support on Dec 21, 2025, 9:57 AM
Yes, this is a 50-foot box containing a continuous length of the SAE 100R7 thermoplastic hose.
