Hose, thermo, Synflex100R7 250 FT/BOX CO

Description & Features

Designed for versatility, the Synflex Optimum by Eaton Aeroquip is a reliable choice for general hydraulics, material handling, chemical transfer, and marine steering applications. The hose features a durable polyurethane cover that is highly resistant to abrasion, ensuring longevity in demanding environments. With its non-conductive construction, this hose is safe for use in sensitive applications where conductivity could be a concern.

The Synflex Optimum is lightweight, being two times lighter than equivalent wire braided rubber hoses, which makes it easier to handle and install. It is reinforced with synthetic fiber and constructed with a 1 ply braid, providing flexibility and strength. The hose is orange in color for easy identification and has a minimum bend radius of 1.25 inches, making it suitable for tight spaces.

SKU: 3TR7N-04-250BC

Supplier Part Number (MPN): 3TR7N-04-250BC

Specifications

Abrasion Resistance 29	Alternate Part Numbers Alternate Part Number MINO-00015X06186	Application General hydraulics, material handling, chemical transfer, marine steering.	Color Orange	Conductivity 13552	Construction 1 Ply Braid	Cover Material Polyurethane	Dash Size -4	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Highly abrasion resistant cover\|Prevents absorption of most oils and fluids\|2X lighter than equivalent wire braided rubber hoses	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 1.25	Minimum Bend Radius 1.25	Minimum Working Temperature -40	Net Pack Quantity Units FT	Product Width 0.49	Reinforcement Material Synthetic fiber	Sub Brand Synflex	Supplier Part Number 3TR7N-04-250BC	Tube Material Nylon	Product Weight 0.21 lbs

Product Questions & Answers (3)

Question by: Wes M on Jul 24, 2025, 7:20 PM

got a tight spot to snake a hose through, how tight can this Synflex 100R7 bend without kinkin it

Answer by: Customer Support on Jul 26, 2025, 6:10 AM

For tight routing, the minimum bend radius on this hose is 1.25 inches. Staying at or above that bend radius helps it keep its shape and flow without stressing the construction.

Question by: Jimmy H on Mar 22, 2026, 3:55 PM

what's the minimum bend radius on this hose? got some tight routing situations under a piece of equipment and need to know if it'll make the turns without kinking

Answer by: Customer Support on Mar 24, 2026, 6:28 AM

1.25 inches is the minimum bend radius on this hose, so it handles pretty tight corners without issue. For routing through confined spaces under machinery, that's a solid spec to work with. Just make sure your routing doesn't force a sharper bend than that, and you should be good to go.

Question by: Judy W on Mar 24, 2026, 8:51 AM

Would this hose hold up for hydraulic use on farm equipment, or is it more for lighter-duty stuff?

Answer by: Customer Support on Mar 25, 2026, 8:26 PM

Designed for general hydraulics, material handling, chemical transfer, and even marine steering, this hose should be suitable for a variety of hydraulic applications including some farm equipment. Its polyurethane cover provides good abrasion resistance, which is important in demanding environments.
