Air Brake Tubing

Description & Features

Designed for truck and trailer air brake systems, this 3/16" OD Eaton Aeroquip Air Brake Tubing is built from high-quality blended polyamide and features an extruded, UV-stabilized black cover rated for service down to -40°F. The lightweight construction supports flexibility without compromising durability under harsh operating conditions, making it well suited for formed tube assemblies, straight air brake harness assemblies, and auxiliary air system routing.

Compliant with DOT FMVSS 106 and certified to SAE J844, SAE J1131, and SAE J2494-3, this tubing meets the regulatory requirements for commercial vehicle brake applications. With a minimum bend radius of 0.75" and compatibility with QCAB and push-to-connect fittings, it integrates readily into standard air brake harness configurations. Part of the Synflex Eclipse series from Danfoss/Eaton, it is sold in 100-foot lengths.

SKU: 4245-0330-0100

Supplier Part Number (MPN): 4245-0330-0100

Specifications

Abrasion Resistance 28	Application Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies.	Certifications SAE J844\|SAE J1131\|SAE J2494-3	Color Black	Compliances DOT FMVSS 106	Construction Extruded	Cover Material UV Stabilized	Dash Size -3	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM FT	Features Light weight to improve hose flexibility\|Maximum durability under harsh operating conditions\|High quality proprietary blended nylon materials	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 0.75	Minimum Bend Radius 0.75	Minimum Working Temperature -40	Net Pack Quantity Units FT	NMFC 70	Product Width 0.19	Qualified Hose Fittings QCAB, Push to Connect	Reinforcement Material Polyamide	Sub Brand Synflex	Supplier Part Number 4245-0330-0100	Tube Material Polyamide	Product Weight 0.05 lbs

Product Questions & Answers (2)

Question by: Brent B on Jul 7, 2025, 9:27 AM

got a roll of this in black, is it actually DOT compliant for air brake work or is it just generic tubing

Answer by: Customer Support on Jul 8, 2025, 9:24 PM

For air brake use, it meets DOT FMVSS 106 compliance and it is also certified to SAE J844, SAE J1131, and SAE J2494-3.

Question by: Rick P on Nov 16, 2025, 8:39 AM

What size brake line fitting works with this tubing?

Answer by: Customer Support on Nov 17, 2025, 4:32 PM

QCAB and push-to-connect fittings are qualified for use with this air brake tubing.
