4247 Solstice

Description & Features

Eaton Aeroquip Synflex 4247 Solstice airbrake hose is designed for truck and trailer air brake systems. Featuring a UV stabilized cover material, this black, non-conductive hose offers premium abrasion resistance. Constructed from high-quality proprietary blended nylon materials, the 4247 Solstice hose is lightweight to improve flexibility while ensuring maximum durability in harsh operating conditions. Compliant with DOT FMVSS 106, SAE J1131, SAE J2494-3, and SAE J844 standards.

Suitable for auxiliary air systems, formed tubes, and straight air brake harness assemblies. Minimum working temperature: -40 degrees. Dash size: -4, with a minimum bend radius of 1 inch.

SKU: 4247-0410-0500

Supplier Part Number (MPN): 4247-0410-0500

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00015X21097	Application Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies.	Certifications SAE J1131\|SAE J2494-3\|SAE J844	Color Black	Compliances DOT FMVSS 106	Conductivity 13552	Construction Extruded	Cover Material UV Stabilized	Dash Size -4	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 12.00	UOM FT	Features Light weight to improve hose flexibility\|Maximum durability under harsh operating conditions\|High quality proprietary blended nylon materials	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 1	Minimum Bend Radius 1	Minimum Working Temperature -40	Net Pack Quantity Units FT	NMFC 70	Product Width 0.25	Reinforcement Material None	Sub Brand Synflex	Supplier Part Number 4247-0410-0500	Tube Material Polyamide Alloy	Product Weight 0.03 lbs

Product Questions & Answers (2)

Question by: Brett T on Jun 16, 2025, 6:43 AM

does this tubing hold up in real cold weather? we run trucks year round and cant afford line failures when its freezing out

Answer by: Customer Support on Jun 17, 2025, 5:40 PM

Rated down to -40 degrees, so cold snaps that would crack lesser tubing are not going to be an issue here. The polyamide alloy construction keeps it flexible even at those low temps, which matters a lot when you're dealing with air brake systems that need to move and bend without getting stiff or brittle.

Question by: Brent P on Jul 20, 2025, 11:46 AM

Can I use this Solstice tubing for the air brakes on my trailer?

Answer by: Customer Support on Jul 22, 2025, 8:53 AM

Absolutely, this tubing is designed specifically for truck and trailer air brake systems, as well as auxiliary air systems.
